SKH-612MS Pioneering c-type double gripper mechanism double drilling heads automatic six sides CNC drilling machine

CNC Drilling Machine – High Precision Woodworking Solution

Introduction

The CNC Drilling Machine is a cutting-edge solution for high-precision drilling in woodworking and furniture manufacturing. With its advanced control system, reliable components, and flexible configurations, this machine is designed to meet the needs of high-volume production environments while maintaining the utmost accuracy and efficiency.

Key Features

21-Inch Color Screen Control Display:
Features a user-friendly, easy-to-operate 21-inch color screen that simplifies machine control, saving space and enhancing safety. The interface is intuitive, with clear operation tips and troubleshooting guidelines for smooth operation.

Precision Drilling Box:
Uses HUAHUA's independently developed CNC drilling box that adheres to international manufacturing standards. After three-coordinate detection, the accuracy of each hole is guaranteed.

Double Clamping and Feeding:
The automatic double-clamping mechanism ensures precise board feeding and positioning, enhancing drilling accuracy and preventing scratches on edge banding tape.

Taiwan Syntec Servo Motor:
Features a high-performance servo motor for fast and precise positioning. The clamp's moving speed reaches up to 130m/min, ensuring quick and efficient operation.

Flexible Discharge (Optional):
Can be equipped with an automatic lifting unloading table. Multiple unloading options are available to ensure easy and automatic connection to other production lines.

Rack and Pinion Transmission:
Utilizes a ball screw drive with an error margin of just 0.05-0.1mm, ensuring high precision and improving the machine's overall lifespan.

Roller Assist Transfer Table:
Helps prevent scratches on sheets, ensuring smooth handling of materials.

Automatic Oil Injection System:
Features a cylinder-type oil injection system that evenly oils all rails, ensuring the smooth operation and extended service life of the machine.

Taiwan Syntec Control System:
Equipped with a high-performance 21-inch PC control panel featuring the Taiwan Syntec control system, enhancing operational ease and reliability.

Specifications

Processing Size Range:

• Min. Width: 50mm
• Max. Width: 1200mm
• Max. Length: 5000mm
• Min. Length: 250mm
• Max. Thickness: 48mm
• Min. Thickness: 10mm

Working Stoke & Max. Position Speed:

• X Axis: 5410mm, 130m/min
• Y Axis: 1630mm, 85m/min
• Z Axis: 140mm, 30m/min
• U Axis: 5410mm, 130m/min
• V Axis: 1340mm, 80m/min
• W Axis: 110mm, 30m/min
• A Axis: 1168mm, 30m/min
• Y2 Axis: 1630mm, 85m/min
• Z2 Axis: 90mm, 30m/min

Top Drilling Unit:

• Vertical Spindles: 12*2
• Horizontal Spindles: 16pcs
• Drilling Box Motor Speed: 2800rpm
• Router Motor Power: 3.5kw, Speed 18000rpm

Bottom Drilling Unit:

• Vertical Spindles: 9pcs
• Drilling Box Motor Speed: 2800rpm
• Router Motor Power: 3.5kw, Speed 18000rpm

Other Data:

• Working Table Height: 960mm
• Total Power: 23.1kw
• Weight: 3850kg
• Working Pressure: 0.7-0.8Mpa
• Overall Size: 284064802200mm

Conclusion

The CNC Drilling Machine offers exceptional precision, durability, and flexibility for high-volume woodworking operations. Its advanced features, including the Taiwan Syntec control system, double clamping mechanism, and automatic oil injection, make it a reliable and efficient choice for manufacturers seeking to streamline their drilling processes while maintaining accuracy.

Product Info Gallery

Let me know if you'd like further adjustments!

21 inch color screen control display

Using 21-inch color screen to control the display,The single-arm suspension is easy to operate and saves floor space.The operation is safe and reliable, the interface is simple and friendly,With complete operation tips and troubleshooting guidelines.

Precision drilling box

Using HUAHUA independently developed CNC drilling box, Manufacturing in accordance with international standards,After three-coordinate detection, the accuracy is guaranteed.

Double clamping and feeding

The double-clamping mechanism is adopted, and the board feeding and positioning are automatically controlled according to the computer drilling program to improve the drilling accuracy.Effectively prevent the edge banding tape from being scratched.

Taiwan's Syntec servo motor

1.Servo control clamp2.Fast and precise positioning3.The clamp moving speed can reach up to 130m/min

Flexible discharge (Optional)

Match with automatic lifting unloading table A variety of unloading options to facilitate automatic connection

Rack and pinion transmission

Using ball screw drive, the screw drive error is within 0.05-0.1MM, the cumulative error is within ±0.2MM, and the service life of the whole machine is improved.

Roller assist transfer table

Prevent sheet scratches

Automatic oil injection system


Cylinder-type oil injection system, all rails use independent cylinders to supply oil, ensuring that all rails are evenly oiled every time.
