SG Cultivator-Hiller Power Tillers

The SG Cultivator-Hiller Power Tiller is a heavy-duty farm implement designed to till soil, remove weeds, mix in nutrients and create raised ridges (hilling). It combines rotary tilling and fertilizer distribution to prepare land for planting on small to large farms.

Model: 3ZPF-2. Weight: 950 kg. Overall dimensions: 1500 × 2200 × 1500 mm.

Recommended driving power is ≥58.8 kW (approximately 80 HP). The unit connects via a three‑point suspension (three‑point hitch) to the tractor.

Working width is 2 × 750 mm (total 1500 mm) and the tiller cultivates 2 rows per pass.

The machine has two fertilizer tanks (2 pcs) with a volume of 0.175 m3 each (~175 liters per tank) and 4 fertilizer outlets. It features an adjustable fertilizer delivery and a large fertilizer bucket for distribution while tilling.

Yes. The planting/row spacing is adjustable within the range 1100–1800 mm, and the space of soil plough per ridge can be set between 1100–1800 mm to suit crop layout.

Cutter roll direction: clockwise. Cutter roll speed: 290 r/min. Number of rotary blades options: 4×6 or 4×12. Drive mode of cutter roll: gear drive.

The SG Cultivator-Hiller is designed for a wide range of soils — light loam to heavier soils — and is built strong and durable to handle tough conditions. Avoid excessive rocky or stony fields that could damage blades and gearbox.

Key maintenance points include gearbox and gear lubrication, inspection and replacement of rotary blades, checking/tightening fasteners, cleaning fertilizer tanks and outlets, and ensuring depth-limiting wheels and side gearbox are functional. Regular greasing of moving joints is recommended.

Always shut off the tractor and remove the key before performing maintenance. Keep bystanders clear of the implement during operation. Wear appropriate PPE, check for loose objects in the field, and do not operate at excessive PTO speeds. Follow tractor and implement safety guidelines.

Use the depth-limiting wheel to set the working depth and the row spacing adjusting device to set the desired planting spacing (1100–1800 mm). Make adjustments with the machine stationary and on level ground.

Its compact dimensions (1500 × 2200 × 1500 mm) and 950 kg weight make it transportable with an appropriate trailer and tractor. For storage, clean soil and fertilizer from the implement, lubricate moving parts, and store in a dry, covered area to prevent corrosion.

Product information lists no local service location. Availability of spare parts and service depends on the supplier or dealer network — confirm with your vendor before purchase and ask about spare blades, gearbox parts and after-sales support.

Match tilling speed and tractor power to field conditions, keep cutter blades sharp, use correct fertilizer rates and outlet settings, perform regular maintenance on gears and gearbox, and work in systematic passes to minimize overlap and rework.

Standard features include a rotary tiller, depth-limiting wheel, side gearbox and row-spacing adjuster. Compatibility with other implements depends on tractor hitch/PTO setup; consult the supplier to confirm mounting and PTO/driveline compatibility for additional attachments.
