Main purpose and scope of use:
1. X-ray baggage scanner can quickly and effectively detect various dangerous items hidden in small items, parcels, mail, small bags, suitcases, shoulder bags, backpacks. Such as guns, knives, detonators, fireworks and firecrackers.
2. And widely used in airports, railway stations, bus stations, high-speed rail stations, customs, express companies, hotels, tourist attractions, government agencies, luggage storage, embassies, sports venues, convention centers, courts, shopping centers, cultural venues , Post office, shoe factory, toy factory, luggage factory, handbag factory, school, prison and other security inspection occasions.
5030:
| Channel size | 500 (width) × 300 (height) mm or custom |
| Conveyor speed | 0.22m/s |
| Conveyor belt rated load | 150 kg |
| Resolution | 0.101 mm diameter wire |
| Penetration | 18 mm steel film |
| Safety | For ISO1600 film |
| Safety leakage dose | <0.05μGy/h |
| X-ray generator | beam direction |
| Tube current | 0.4~0.5mA (adjustable) |
| Tube voltage | 80 KV (adjustable) |
| Beam divergence angle | 60° |
| Cooling / duty cycle | sealed oil cooling / 100% |
10080:
| Channel size | 1000 (width) × 800 (height) mm or custom |
| Conveyor speed | 0.22m / s |
| Conveyor belt rated load | 220 kg |
| Resolution | 0.101 mm diameter metal wire |
| Spatial resolution | Horizontal:1.3 mm in diameter Vertical:1.0 mm in diameter |
| Penetration resolution | diameter 0.511 mm |
| Penetration | 34 mm steel plate |
| Film Safety | ISO1600 Film Safety |
| Leakage dose | <0.1μGy/h |
Unique features:
1. Sound and light alarms are issued when the sound and light alarms meet the conditions.
2. Energy-saving design: The machine can automatically sense the object, and the baggage is put on the machine to start running. No baggage, the machine is still.
3. Environmental design: lead curtain plus protective film to prevent customers from touching lead and avoid lead pollution.
4. Dynamic picture switching: The picture can be switched when it is still, and it can be switched freely when it is dynamic.
5. The eagle eye can easily see the current zoomed area
6. One-button shutdown control: Only need to rotate the key when shutting down, the device automatically shuts down safely, reducing equipment failure.
Use environment:
| Working temperature/humidity | 0°C~45°C/20%~95% (non-condensing) |
| Storage temperature / humidity | -20 ° C ~ 60 ° C / 20% ~ 95% (non-condensing) |
| Working voltage | 220VAC (±10%) 50±3HZ |
| Power loss | 1.5KW (maximum) |
| Noise level | <58dB |
