SBM Gold Processing Plant Dry Electric Wet Tantalite Magnetic Separator
- Section : Machinery
- Category : Mineral Separators
- SKU : 60402920662
SBM Gold Processing Plant Dry Electric Wet Tantalite Magnetic Separator Conveyor Belt Magnetic Separator
Product Overview:
The SBM Gold Processing Plant is equipped with advanced Dry Electric Wet Tantalite Magnetic Separators and Conveyor Belt Magnetic Separators for efficient processing of gold and other minerals. It is designed to handle the toughest materials in mining and is an essential tool in gold recovery. The plant utilizes a variety of stages to ensure maximum extraction and purity.
Technical Specifications
| Model | Roller Size (mm) | Magnetic Intensity (mT) | Processing Ability (T/h) | Drive Power (Kw) | Weight (Kg) |
|---|---|---|---|---|---|
| CTS(N,B)-46 | 400×600 | 130 (average), 160 (highest) | 1-3 | 1.1 | 600 |
| CTS(N,B)-66 | 600×600 | 145 (average), 170 (highest) | 5-10 | 1.1 | 750 |
| CTS(N,B)-69 | 600×900 | 145 (average), 170 (highest) | 8-15 | 1.1 | 830 |
| CTS(N,B)-612 | 600×1200 | 145 (average), 170 (highest) | 10-20 | 2.2 | 990 |
| CTS(N,B)-618 | 600×1800 | 145 (average), 170 (highest) | 15-30 | 2.2 | 1330 |
| CTS(N,B)-712 | 750×1200 | 120 (average), 155 (highest) | 15-30 | 3.0 | 1500 |
Key Features:
- High Intensity: Utilizes high-power rare earth magnets for efficient separation.
- Versatility: Suitable for both dry and wet operations.
- Heavy Contamination Handling: Equipped with angle deflectors for better contamination management.
- Easy Maintenance: Designed for easy cleaning and maintenance, with direct access to magnets in chutes.
- Customized Solutions: Available with flanges for both square and round chutes, meeting diverse installation requirements.
Gold Processing Plant Stages
Crushing & Screening:
- Gold ore is first fed into jaw crushers and mobile stations for coarse crushing. Then, secondary crushers like the HCS single cylinder hydraulic cone crusher are used for further reduction.
Grinding:
- The crushed gold ore is ground in ball mills, and spiral classifiers are used for efficient sorting. Wet and dry grinding methods are available.
Magnetic Separation:
- The use of magnetic separators removes unwanted iron and magnetic materials, ensuring the purity of the gold content.
Drying:
- The final gold powder is processed through a drying machine to remove excess moisture, preparing it for further processing or packaging.
Applications
- Gold Mining: Effective for gold ore processing and extraction.
- Mineral Processing: Suitable for separating various minerals like tantalite and other metal ores.
- Magnetic Separation: Used for removing ferrous contaminants from ore in mining operations.
Production Process Example
- Customer Case: The SBM Gold Processing Plant is deployed in various high-demand locations such as Saudi Arabia, where the climate and working conditions are challenging. The production line includes jaw crushers, multi-cylinder hydraulic cone crushers, and magnetic separators, producing up to 360 tons per hour with an output grain size of -12mm.
This solution helps ensure continuous and efficient operation in harsh environments, maintaining a stable production line for the mining industry.
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What is the SBM Gold Processing Plant used for?
The SBM Gold Processing Plant is designed for efficient processing of gold and other minerals, utilizing advanced Dry Electric Wet Tantalite Magnetic Separators and Conveyor Belt Magnetic Separators.
2. What are the key features of the SBM Gold Processing Plant?
Key features include high-intensity separation using rare earth magnets, versatility for both dry and wet operations, heavy contamination handling, easy maintenance, and customized solutions for various installation requirements.
3. What types of materials can the SBM Gold Processing Plant process?
The plant can process gold ore and other minerals, such as tantalite, as well as separate ferrous contaminants from ores in mining operations.
4. How does the magnetic separation process work?
The magnetic separation process uses powerful magnets to remove unwanted iron and magnetic materials from the ore, ensuring the purity of the gold content.
5. What are the processing capabilities of the different models?
The processing capabilities vary by model, with options ranging from 1-31.1 T/h for the CTS(N,B)-46400×600 model to 15-30 T/h for the CTS(N,B)-712750×1200 model.
6. Is the SBM Gold Processing Plant suitable for harsh environments?
Yes, the plant is designed to operate efficiently in challenging conditions, such as those found in Saudi Arabia, maintaining a stable production line.
7. What is the maintenance routine for the SBM Gold Processing Plant?
The plant is designed for easy maintenance, with direct access to the magnets in chutes for cleaning and upkeep, ensuring optimal performance.
8. Can the SBM Gold Processing Plant be customized?
Yes, the plant is available with customized solutions, including flanges for both square and round chutes to meet diverse installation requirements.
9. What is the drying process for the final gold powder?
The final gold powder is processed through a drying machine to remove excess moisture, preparing it for further processing or packaging.
10. What types of crushers are used in the gold processing plant?
The plant employs jaw crushers for coarse crushing, followed by secondary crushers like the HCS single cylinder hydraulic cone crusher for further reduction.
11. How does the grinding process work in the processing plant?
Crushed gold ore is ground in ball mills, with spiral classifiers used for efficient sorting, allowing for both wet and dry grinding methods.
12. What is the average magnetic intensity of the separators?
The average magnetic intensity ranges from 120 mT to 145 mT, depending on the specific model of the magnetic separator.
13. What is the weight of the SBM Gold Processing Plant models?
The weight of the models varies, with the lightest model weighing 600 kg and the heaviest model weighing 2990 kg.
14. What is the expected output grain size from the processing plant?
The production line can achieve an output grain size of -12 mm, ensuring efficient processing of gold ore.
15. Can the SBM Gold Processing Plant handle heavy contamination?
Yes, the plant is equipped with angle deflectors specifically designed to handle heavy contamination effectively.
