Product Paramenters
| AIRCRAFT PARAMETERS | |
| Architecture Layout | Six-axis layout |
| Maximum Wheelbase | 2260mm |
| Overall Dimension | 2145mm × 2045mm × 865mm (arm unfolded, blade unfolded) 1138mm×682 mm×790mm(packing) |
| Weight Of Machine | 35KG |
| FLIGHT PARAMETERS (Fly only within line of sight) | |
| Hovering Accuracy | RTK: Horizontal ±10cm, Vertical ±10cm Radar: ±0.1m |
| Hovering Under Spraying And Full Load | 7min |
| Hovering Under Spreading And Full Load | 7min |
| No-load Hovering | 18min |
| Maximum Operation Efficiency | 22 ha/h |
| Ranging Accuracy Of Ground Simulating Radar | 0.1m |
| Fixed Height Range | 1-30m |
| Obstacle Avoidance Perception Range | 1-30m |
| Graphic Transmission | >1.5KM |
| Maximum Take-off Weight | Spraying:45kg Sowing:43kg |
| SPRAYING SYSTEM | |
| Nozzle Type | Centrifugal nozzle |
| Number Of Nozzles | 4 nozzles |
| Max. Flow | 8L/min |
| Maximum Spraying Width | 11m |
| GENERATOR | |
| Nominal Power | 220V/8000W (direct connection to generator) 220V/2200W (direct connection to mains)" |
| Tank Capacity | 20L |
| Reference Fuel Consumption | 500ml/kWh |
| SMART BATTERY | |
| Battery Weight | 13KG |
| Power Battery | 78.3V/30000mAh 2.1kwh |
| Charging Duration | Lithium battery 20%-95% about 13min |
| HD540PRO CHARGER | |
| Input Voltage | Input Voltage |
| Maximum Power | Maximum Power |
FAQ
Full-load Spraying Hover Time:8.5Min
Full-load Spread Hover Time:7Min
No-load Hover Time:21min
18S ,30000mAh , 68.4V, 21kwh Lithium Battery
can be cycled 1000 times
13 minutes to fully charge a battery
Recommended purchasing quantity
2 Batteries ,1pcs Generator and 1pcs Charger
4 batteries and 1pcs Charger
The Battery posses bigger eletric power and super charge capability,which is built smarter,stronger and safer.2 batteries charged at the same time realize non-stop operations in fields
Multiple selection: 220V / 380V input is supported
38L large fuel tank, the maximum rated power is 8500W
220V 8000W - Directly connect to the generator
220V 2200W - Directly connect to the mains
Input Voltage :Support 220V / 380V
Maximum Power :8000W
We provide both T40 spray tank and T60/50 fertilizer tank.
6-Operation Efficienc
Max Operation efficiency:330Mu/h or 22Ha/h
7-Max Take-off Weight
Spraying:88Kg
Spreading:95kg
T60/50 Fertilizer Tank
T40 Spray Tank
Nozzle Types
Centrifugal Nozzles
Number Of Nozzles:2 / 4 Nozzles
Max Flow:13.5L/Min
Maximum Spray Amplitude:12M
High Pressure Nozzles
Number Of Nozzles:4 Nozzles
Max Flow:8L/Min
Maximum Spray Amplitude:11M
Equipped with the FPV camera and landing light to ensure night timeoperation safe and reach the real-time monitoring through the LCD Screen.
Remote control operation display
| Architecture Layout | Six-axis layout |
|---|---|
| Maximum Wheelbase | 2260mm |
| Overall Dimension | 2145mm × 2045mm × 865mm(arm unfolded, blade unfolded)1138mm×682 mm×790mm(packing) |
| Weight Of Machine | 35KG |
| Hovering Accuracy | RTK: Horizontal ±10cm,Vertical ±10cm Radar: ±0.1m |
| Hovering Under Spraying And Full Load | 7min |
| Hovering Under Spreading And Full Load | 7min |
| No-load Hovering | 18min |
| Maximum Operation Efficiency | 22 ha/h |
| Ranging Accuracy Of Ground Simulating Radar | 0.1m |
| Fixed Height Range | 1-30m |
| Obstacle Avoidance Perception Range | 1-30m |
| Graphic Transmission | >1.5KM |
| Maximum Take-off Weight | Spraying:45kg Sowing:43kg |
| Nozzle Type | Centrifugal nozzle |
| Max. Flow | 8L/min |
| Maximum Spraying Width | 11m |
| Nominal Power | 220V/8000W(direct connection to generator)220V/2200W(direct connection to mains)" |
| Tank Capacity | 20L |
| Reference Fuel Consumption | 500ml/kWh |
| Battery Weight | 13KG |
| Power Battery | 78.3V/30000mAh 2.1kwh |
| Charging Duration | Lithium battery 20%-95% about 13min |
| Full-load Spraying Hover Time | 8.5Min |
| Full-load Spread Hover Time | 7Min |
| No-load Hover Time | 21min |
| Multiple selection | 220V / 380V input is supported |
| Input Voltage | Support 220V / 380V |
| Maximum Power | 8000W |
| Max Operation efficiency | 330Mu/h or 22Ha/h |
| Spraying | 88Kg |
| Spreading | 95kg |
The maximum flight time under no-load conditions is approximately 18 minutes, while full-load spraying has a hover time of about 8.5 minutes.
The weight of the JT40 UAV Spray Agricultural Drone is 35 kg.
The JT40 UAV can spray with a maximum width of 11 meters.
The lithium battery can be charged from 20% to 95% in approximately 13 minutes.
The drone features a tank capacity of 20 liters.
The JT40 UAV is equipped with centrifugal nozzles, and it can have either 2 or 4 nozzles depending on the configuration.
The maximum take-off weight for spraying is 88 kg.
The JT40 UAV has a maximum operation efficiency of 22 hectares per hour.
Yes, the JT40 UAV can be used for both spraying and sowing, with a maximum take-off weight of 45 kg for spraying and 43 kg for sowing.
The drone can operate effectively within a range of over 1.5 kilometers for graphic transmission.
Yes, the JT40 UAV is equipped with an obstacle avoidance perception range of 1-30 meters.
The drone uses a lithium battery with a capacity of 78.3V and 30,000 mAh.
The generator supports multiple inputs, including 220V and 380V, with a maximum rated power of 8500W.
The smart battery weighs 13 kg.
Yes, the JT40 UAV is equipped with an FPV camera and landing light for real-time monitoring and safe night operations.
