HD-72-SATA Industrial Equipment Specifications — image 1

HD-72-SATA Industrial Equipment Specifications
Test Instruments

HD-72-SATA Industrial Equipment Specifications

  • SKU: 1600828765847
  • Category: Test Instruments

The HD-72-SATA is an industrial-grade unit designed for high-performance tasks requiring controlled environments. Below are the detailed specifications for this equipment:

R182,200

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options
SKU:
1600828765847
Payment security and privacy badges

Product Description

HD-72-SATA Industrial Equipment Specifications

The HD-72-SATA is an industrial-grade unit designed for high-performance tasks requiring controlled environments. Below are the detailed specifications for this equipment:

Key Features:

  • Customized Support: Available for OEM and ODM requests to fit specific operational needs.
  • Place of Origin: China
  • Brand Name: HD
  • Model Number: HD-72-SATA

Dimensions:

  • Inner Box Size: W500 x D400 x H1020 mm
  • Outer Box Size: Approximately W1250 x D1350 x H1910 mm
  • Inner Box Volume: 204L
  • Weight: Around 930 kg

Opening and Cooling:

  • Opening Method: Single door, right-opening for easy access and operation.
  • Cooling Method: Air-cooled, providing effective heat dissipation for longer-lasting performance.

Power Specifications:

  • Power Supply: AC 220V, requiring about 12KW for optimal functioning. This ensures the machine runs efficiently and consistently under industrial load.

Applications:

This unit is ideal for industrial environments requiring precise environmental control. It can be customized for specific tasks or industries such as manufacturing, electronics, or high-performance testing applications.

Additional Notes:

The unit's air-cooled design and large internal volume make it suitable for various testing or storage applications. The heavy-duty construction (930 kg) ensures durability, making it an excellent choice for demanding environments.

Information
ModelHD-72-SATA
Inner box sizeW500×D400×H1020mm
Outer box sizeAbout W1250×D1350×H1910mm
volume204L
Opening methodSingle door (right open)
cooling methodair-cooled
weightAbout 930KG
power supplyAC 220V About 12KW



Temperature parameter
temperature range-70℃~150℃
Temperature fluctuation≤±0.5℃
≤±1℃
temperature offset≤±2℃
temperature resolution0.01℃
Heating rate5℃/min(mechanical cooling, under standard load)
temperature change rateHigh temperature can meet 5℃~8℃/min nonlinear adjustable (measured at the air outlet, mechanical refrigeration, under standard
load), low temperature can meet 0℃~2℃/min nonlinear
Adjustable (measured at the air outlet, mechanical cooling, under normal load)
temperature uniformity≤±2℃
standard load10KG aluminum block, 500W load;



Test standard
GB/T5170.2-2008 Temperature test equipment
GB/2423.1-2008 (IEC60068-2-1:2007) low temperature test method AB.
GB/2423.2-2008 (IEC60068-2-2:2007) high temperature test method BA.
GJBl50.3 (MIL-STD-810D) high temperature test method.
GJBl50.4 (MIL-STD-810D) low temperature test method.



Control System
DisplayColor LCD display
Operation modeProgram mode, fixed value mode
SettingChinese and English menu (optional), touch screen input
Setting rangeTemperature: Adjust according to the temperature working range of the equipment (upper limit +5°C, lower limit -5°C)
display resolutionTemperature: 0.01°C
Time: 0.01min
control methodBTC balanced temperature control method + DCC (intelligent cooling control) + DEC (intelligent electrical control) (temperature
test equipment)
BTHC balanced temperature and humidity control method + DCC (intelligent cooling control) + DEC (intelligent electrical control)
(temperature and humidity test equipment)
Curve record functionIt has RAM with battery protection, which can save the set value, sampling value and sampling time of the device; the maximum
recording time is 350 days (when the sampling period is 1.5min)
Accessory functionFault alarm and cause, processing prompt function
Power-off protection function
Upper and lower limit temperature protection function
Calendar timing function (automatic start and automatic stop operation)
self-diagnosis function

Frequently Asked Questions

What is the primary application of the HD-72-SATA?

The HD-72-SATA is designed for industrial environments requiring precise environmental control, making it ideal for manufacturing, electronics, and high-performance testing applications.

What are the dimensions of the HD-72-SATA?

The inner box dimensions are W500 x D400 x H1020 mm, while the outer box dimensions are approximately W1250 x D1350 x H1910 mm.

What is the weight of the HD-72-SATA?

The HD-72-SATA weighs around 930 kg, ensuring durability for demanding environments.

How is the HD-72-SATA cooled?

The unit employs an air-cooled method for effective heat dissipation, which helps in maintaining performance over extended use.

What power supply is required for the HD-72-SATA?

The HD-72-SATA requires an AC 220V power supply with approximately 12KW for optimal functioning.

What temperature range can the HD-72-SATA achieve?

The HD-72-SATA can operate within a temperature range of -70℃ to 150℃.

What control features does the HD-72-SATA offer?

It features a color LCD display, program mode, fixed value mode, and supports both Chinese and English menus via touch screen input.

What is the temperature fluctuation tolerance of the HD-72-SATA?

The temperature fluctuation is ≤±0.5℃, ensuring precise temperature control.

Does the HD-72-SATA have any alarm functions?

Yes, it includes a fault alarm and cause processing prompt function, as well as upper and lower limit temperature protection.

What kind of customization options are available for the HD-72-SATA?

The HD-72-SATA supports OEM and ODM requests, allowing customization to fit specific operational needs.

What are the standard test methods that the HD-72-SATA complies with?

It complies with GB/T5170.2-2008 for temperature test equipment and GB/2423.1-2008 and GB/2423.2-2008 for high and low temperature test methods.

What is the temperature resolution of the HD-72-SATA?

The temperature resolution of the HD-72-SATA is 0.01℃.

What safety features does the HD-72-SATA have?

It has power-off protection, upper and lower limit temperature protection, and a self-diagnosis function.

Can the HD-72-SATA record temperature data?

Yes, it includes a curve record function with RAM that can save set values, sampling values, and has a maximum recording time of 350 days.

What is the heating rate of the HD-72-SATA?

The heating rate can reach up to 5℃/min under standard load conditions.
