Food Snakcs Filling Automatic Multi-Function Packaging Machine

It is a mechanical liquid packaging machine (model DF-50SYP) designed for high-efficiency, four-side sealed sachet/pouch packing of liquids and semi-liquids such as sauces, jams, juices, yogurt, oils, shampoos and hand sanitizers.

Applications include food (sauces, condiments, jams, yogurt, oils), beverages (juices, drinks), medical/pharmaceutical liquids, and chemical/cleaning products.

Model DF-50SYP; filling range 3–100 ml; bag size L: 50–135 mm, W: 40–140 mm; speed 30–50 bags/min; four-side sealing; piston filler; stainless steel (SUS304) body; total power 2.2 kW; voltage 220V 50/60Hz; machine weight ≈280 kg; dimensions 1000 × 800 × 1660 mm (L×W×H).

It uses roll film to form sachets/pouches. Compatible film materials include composite films such as Metal (AL), Paper, OPP/CPP, PET/PE, PA, EVOH and other laminated roll films.

The machine performs four-side sealing and offers cutting styles including zigzag (serrated) or flat scissor-type cuts, depending on your finished-package preference.

A stainless-steel piston filler is used, suitable for a wide range of viscosities from thin liquids (drinks, oils) to thicker products (sauces, jams, yogurt). Heavily particulate or very chunky products should be tested to confirm performance.

The piston filling system and stepper-motor control provide high repeatability and precise bag length control. Actual fill accuracy depends on product viscosity and calibration—final accuracy is established during machine commissioning and testing.

Bag length and other parameters are set via the touch-screen HMI. The stepper motor allows bag-length adjustments without stopping the machine. Film loading uses a clip-on film mechanism for quick changeovers; typical changeover time is short and depends on operator familiarity.

Yes. The touch-screen interface simplifies operation and speed regulation. The stainless-steel construction and sanitary piston filler make cleaning straightforward. Routine maintenance includes regular cleaning of filling components, inspection of seals, and scheduled lubrication.

Standard electrical supply: 220V 50/60Hz, total electrical power 2.2 kW. The machine footprint and approximate weight should be considered when siting (1000 × 800 × 1660 mm; ~280 kg). Additional utilities (e.g., compressed air, drainage) depend on optional accessories and site setup—please confirm with the supplier.

Typical packing speed is 30–50 bags per minute. Actual throughput depends on bag size, product viscosity, film type and operator setup.

Yes. The clip-on film filling design allows the machine to continue operating even with minor static in the film, reducing stoppages for small film issues.

Yes. Optional accessories and customizations (e.g., date coders, conveyors, special nozzles, gas-flush or downstream equipment) can usually be supplied or integrated. Contact the manufacturer/supplier to discuss specific requirements.

Certifications, warranty terms and after-sales support options vary by supplier and region. Please contact us or your local representative to obtain details about CE/ISO compliance, warranty length, spare parts and service contracts.

Contact the supplier with your product details (viscosity, particulates, desired bag size, film type and required output). The supplier can provide a formal quote, arrange product tests on the machine and discuss lead time, shipping and installation.
