Flat Bed Heavy Duty Horizontal Lathe Machine 1000mm Machining Length 220V 6 Station Tool Rest Hydraulic Chuck Tailstock Electric
The Flat Bed Heavy Duty Horizontal Lathe Machine is a strong and reliable machine for cutting metal. It works well in busy shops and factories. This machine can handle big and heavy jobs with ease. It gives you smooth and accurate cuts every time. The Flat Bed Heavy Duty Horizontal Lathe Machine comes with a powerful spindle and a strong bed. It is easy to use and built to last.
Specifications
| Attribute | Details |
|---|---|
| Type | Horizontal |
| Model Number | CNC6150 |
| Brand Name | PRECISION |
| CNC Control System | GSK |
| Number of Axes | 3 |
| Number of Spindles | Single |
| Tool Post Stations | 6, 4 |
| Max. Length of Workpiece (mm) | 850, 1350, 1850, 2850 |
| Max. Weight of Workpiece (kg) | 120 |
| Travel (X Axis) (mm) | 260 |
| Travel (Z Axis) (mm) | 1000 |
| Width of Bed (mm) | 400 mm |
| Range of Spindle Speed | 30 - 2000 |
| Cutting Torque | 350 |
| Positioning Accuracy (mm) | ±0.01 |
| Repeatability (X/Y/Z) (mm) | ±0.005 |
| Machining Capacity | Heavy Duty |
| Voltage | 380 V, 220 V |
| Dimension (L*W*H) | 2800/1680/1680 |
| Weight | 2800 |
| Key Selling Points | Automatic |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Warranty | 1 Year |
| Free Replacement Parts & Online Technical Support | 100.0% ≤2h |
| Selling Units | Single Item |
| Single Gross Weight | 3200.000 kg |
