200M-300M Water Well Drilling Rig With Crawler (CIF Tanzania Port of Dar es Salaam)

Although the product name indicates 200M-300M, this model is rated for a maximum drilling depth of 360 meters according to the specifications.

The rig uses drill pipe with a diameter of 51 mm. Final bore diameter will depend on the drill bit and casing chosen for the project.

The rig weighs 4000 kg and its dimensions are 3.7 m (L) x 2.0 m (W) x 2.2 m (H), making it compact enough for transport on a suitable flatbed truck or trailer.

Key components listed include the motor, pump and engine. For exact models, power ratings and included accessories, contact the supplier for the configuration sheet.

The crawler undercarriage gives the rig on-site mobility across uneven and soft terrain, allowing the machine to be maneuvered and positioned without needing a separate transport vehicle for short moves.

The rig is equipped with an onboard engine as a core component. Specific engine model, power output and fuel type (for example diesel) can vary by configuration — confirm available options with the manufacturer or dealer.

The rig comes with a 1-year warranty. After-sales support typically includes spare parts supply and technical assistance; extended service plans may be available from the supplier.

It is designed for drilling water wells, geological exploration and testing, groundwater monitoring and installation of environmental monitoring wells.

Yes. With a maximum depth of 360 m and design emphasis on high productivity, the rig is intended for deep water well projects and tasks requiring efficient drilling.

Regular maintenance includes daily inspections, lubrication of moving parts, scheduled servicing of the engine, motor and pump, and timely replacement of wear items (drill bits, seals, hoses). Follow the manufacturer's maintenance schedule and service manual.

The rig is primarily intended for rotary-type water well drilling using 51 mm drill pipe and standard drilling bits and casings. For other specialized methods or tooling compatibility, consult the supplier.

Common accessories and spare parts include additional drill pipes, drill bits, casing pipes, mud pumps or upgrades, hoses, seals and a parts kit. Ask the supplier for packaged options and recommended spare parts for your expected workload.

Operators should be trained and familiar with the rig's manual. Use appropriate PPE, implement machine guarding and emergency-stop procedures, ensure stable siting and leveling before drilling, and follow all local safety regulations. The supplier can often provide safety documentation and training options.
