Yitai High Speed Computerized Jacquard Needle Loom Machine:

The machine can produce different types of elastic and non-elastic narrow tapes, width from min. 2mm to 160mm, lines from 2 lines to 12 lines.

00:00

00:45

Hooks	256	320	384	480	640	768	Operating width(MM)
YTB-C 4/65	√	√	√	√	√	√	560
YTB-C 6/45	√	√	√	√		√	560
YTB-C 4/80	√	√	√	√	√	√	610
YTB-C 6/55	√	√	√	√	√	√	610
YTB-C 8/30	√	√	√			√	610
YTB-C 8/45	√	√	√	√		√	730
YTB-C 8/55	√	√	√	√			860
YTB-C 6/65	√	√	√	√	√		860
YTB-C 6/80	√	√	√	√	√		860
Motor	2 HP Double rapid
Speed	1000 RPM
Heald frame	4-8 pcs
Normal attachment	27- yarn creel places, software, jacquard normal arrachment
Optional attachment	Rubber feeder, beam, back take-off device, double hook single needle system
Above table only shows few machine models, more models are welcome to contact us directly.

Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 14 Dec, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.

1. What types of products can the Yitai Electronic Auto Weaving Machine produce?

The machine produces elastic and non-elastic narrow tapes and bands (e.g., elastic rubber, webbings, straps) with widths from 2 mm to 160 mm and 2 to 12 lines.

2. What is the maximum production speed of the machine?

The machine runs at up to 1000 RPM (rotations per minute), driven by a 2 HP double-rapid motor.

3. What are the available operating widths and model references?

Available models (e.g., YTB-C series) cover common operating widths such as 560 mm, 610 mm, 730 mm, and 860 mm. Specific hook configurations (256–768 hooks) and model variants determine exact usable widths—please contact us for a model matching your width requirement.

4. How many hooks and lines does the loom support?

Hook counts range from 256 to 768 depending on model. The machine supports 2 to 12 lines (woven tape lanes) depending on configuration.

5. What patterning/control features does the machine have?

It's a computerized Jacquard (needle loom) with software for pattern control, enabling complex jacquard designs and computerized selection of needle actions.

6. How many heald frames does the machine use?

Standard heald frame configurations range from 4 to 8 pieces, depending on the chosen model and required weave complexity.

7. What standard attachments come with the machine?

Normal attachments include a 27-place yarn creel, operating software, and standard jacquard attachments. Exact accessories can vary by model.

8. What optional attachments are available?

Optional items include a rubber feeder (for elastic rubber), additional beam options, back take-off devices, and a double-hook single-needle system for specialized production.

9. Can the machine handle different yarn types and elastic rubbers?

Yes — it is designed for a range of yarns and elastic rubbers used in narrow fabric production. For best results, provide yarn specifications so we can recommend suitable settings and optional feeders.

10. How easy is it to change width, pattern, or product setup?

The computerized jacquard and modular attachments make pattern changes and product changeovers relatively quick; however actual setup time depends on yarn, width change, and required tooling. We recommend operator training for efficient changeovers.

11. What are the installation and power requirements?

The machine uses a 2 HP motor; exact electrical requirements (voltage/phase) and foundation/space needs depend on the selected model and local standards. Please provide your site electrical specifications so we can give precise requirements.

12. What maintenance is required and how often?

Routine maintenance includes cleaning lint and debris, lubrication of moving parts, checking tension and alignment, and periodic inspection of needles/hooks. Frequency depends on usage; daily basic checks and scheduled preventive maintenance (weekly/monthly) are recommended.

13. Are spare parts and technical support available?

Yes — spare parts (needles, hooks, belts, electronic parts) and technical support are available. Contact the supplier for parts lists, lead times, and service options.

14. Can this machine be customized or are there more models?

Yes — the listed models are examples. Yitai offers additional models and custom configurations to match specific width, hook count, attachments, or production needs. Contact sales with your requirements for a tailored solution.
