YIBAO Wood Chipper Crusher Machine — image 1

YIBAO Wood Chipper Crusher Machine
Woodworking Machinery

YIBAO Wood Chipper Crusher Machine

  • SKU: 1601194988333
  • Category: Woodworking Machinery

The YIBAO 600-35 Wood Chipper Crusher Machine is a diesel-powered branch processing unit with a chain plate conveyor feeding system. It delivers a processing capacity of 1–2 tons per hour and is powered by a 35-horsepower diesel engine with electric start.The machine us...

R273,887

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options
Section:
Machinery
SKU:
1601194988333
Payment security and privacy badges

Product Description

The YIBAO 600-35 Wood Chipper Crusher Machine is a diesel-powered branch processing unit with a chain plate conveyor feeding system. It delivers a processing capacity of 1–2 tons per hour and is powered by a 35-horsepower diesel engine with electric start.

The machine uses a 300 mm rotor operating at 3000 r/min. Its H12 alloy cutting system comprises four dynamic blades and one static blade, each with a blade length of 155 mm. A 280 mm feed roller is driven by a hydraulic motor.

- Manual three-position feed control: forward, reverse and stop
- Intelligent feeding automatically stops when engine load is high and resumes when the load decreases
- One-touch switching between automatic and manual feeding modes
- 360-degree rotating discharge port with discharge height adjustment
- 600 x 400 mm feed charge door and 300 x 200 mm feed throat
- 13-inch aluminium alloy wheels with 160/70R13C tyres
- Rear lights, feed illumination lights and a foldable hand-operated jack
- Adjustable traction height

The unit measures 3200 x 1300 x 1850 mm and weighs 900 kg. It also includes a 12 V, 120 Ah battery, a 1500 W generator, a 20 L diesel tank and a 25 L hydraulic oil tank.

Key Specifications

Unit Type600-35
Capacity1–2 tons per hour
Power Supply35-horsepower diesel engine
Starting ModeElectric start
Overall Dimensions3200 x 1300 x 1850 mm
Weight900 kg
Host Rotation Speed3000 r/min
Rotor Diameter300 mm
Feed Roller Diameter280 mm
Blade ConfigurationH12 alloy: 4 dynamic blades and 1 static blade
Blade Length155 mm
Feed Throat300 x 200 mm

Frequently Asked Questions

What is the output capacity of the YIBAO Wood Chipper Crusher Machine?

The YIBAO Wood Chipper Crusher Machine has an output capacity of 1-2 tons per hour, making it suitable for high-volume wood processing.

What motor power does the machine use?

The machine is equipped with a powerful 22 kW motor, providing sufficient power for efficient wood crushing and chipping.

Is the YIBAO Wood Chipper Crusher Machine easy to operate?

Yes, the machine is designed with user-friendly controls for easy operation, allowing for quick setup and minimal training time.

What are the dimensions of the machine?

The compact design of the machine measures 2.3 x 1.3 x 1.8 meters, making it easy to install in various settings.

How much does the YIBAO Wood Chipper Crusher Machine weigh?

The machine weighs 800 kg, indicating a robust construction that can handle tough wood chipping tasks.

What types of wood can this machine process?

The YIBAO Wood Chipper Crusher Machine is multifunctional and can process different types of wood into smaller chips for various applications.

Are there different voltage options available for this machine?

Yes, the YIBAO Wood Chipper Crusher Machine is available in both 220V and 380V versions to suit different electrical requirements.

Does the machine come with a warranty?

Yes, the YIBAO Wood Chipper Crusher Machine comes with a 1-year warranty, ensuring long-term reliability and support.

What kind of test reports are provided with the machine?

Machinery test reports and video outgoing inspections are provided to guarantee the machine’s performance and quality before delivery.

What is the maximum diameter of wood branches that this machine can handle?

The maximum diameter of wood branches for the GEB-6130 model is 130 mm, while the GEB-6145 model can handle branches up to 250 mm in diameter.

How many blades does the machine have?

The GEB-6130 model features 4 moving blades and 1 stationary blade, while the GEB-6145 model has the same configuration.

What is the speed of the machine's cutter roller disc?

The cutter roller disc speed for the GEB-6130 model is 2600 r/min, and for the GEB-6145 model, it is 2500 r/min.

What applications can the wood chips be used for?

The processed wood chips can be used for various applications, including biomass fuel production and landscaping.

What is the packing size of the machine?

The packing size for the GEB-6130 model is 2400 x 1400 x 1100 mm, and for the GEB-6145 model, it is 3350 x 1850 x 1550 mm.

How can I receive support if I have issues with the machine?

You can contact our customer support team for assistance with any issues or concerns regarding the YIBAO Wood Chipper Crusher Machine.
