X6330 Vertical and Horizontal Milling Machine Gear Head Drilling Milling Machine

SKU: 1601394601088
Category: Mining Machinery

The X6330 Vertical and Horizontal Milling Machine is a high-quality gear head drilling and milling machine. It is designed for medium-duty machining tasks. This versatile machine is perfect for both professional workshops and small fabrication shops. With its advanced f...

R135,000

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Mining Machinery
SKU:: 1601394601088

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

21 Dec, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

X6330 Vertical and Horizontal Milling Machine

Specifications

Attribute	Details
Model Number	X6330
Spindle Speed Range	80-1400 (V-16steps), 45-1350 (H-12steps)
Spindle Taper	MT4 (V) / NT40 (H)
Spindle Motor	2.2KW / 3.7KW
Spindle Stroke	127mm
X/Y/Z Axis Travel	900 / 420 / 400 mm
Table Size	1370 x 305 mm
Milling Head Rotation	90° left and right, 45° back and forth
T Slot (number-width-pitch)	3 - 16 x 65 mm
Voltage	380V (optional)
Weight	1980 kg
Max. Table Load	150 kg

Key Features

High-quality gear head design for durability.
Multifunctional capabilities for various machining tasks.
Precise table travel of 900mm (X), 420mm (Y), and 400mm (Z).
Flexible spindle speeds from 80 to 1400 r.p.m.
Robust construction with a weight of 1980 kg.

Applications

Ideal for precision machining in metalworking shops.
Suitable for fabricating parts in engineering projects.
Used for milling, drilling, and tapping operations.
Perfect for both small and medium production runs.
Helpful for educational purposes in technical training.

Product Info Gallery

Product Image

Frequently Asked Questions

What is the model number of the milling machine?

The model number of the milling machine is X6330.

What types of machining tasks can the X6330 perform?

The X6330 can perform milling, drilling, and tapping operations, making it suitable for various machining tasks.

What is the spindle speed range for this machine?

The spindle speed range is 80-1400 r.p.m. for vertical milling and 45-1350 r.p.m. for horizontal milling.

What is the maximum table load capacity?

The maximum table load capacity is 150 kg.

How much does the X6330 milling machine weigh?

The X6330 milling machine weighs 1980 kg.

What are the dimensions of the travel for the X, Y, and Z axes?

The travel dimensions are 900 mm for the X-axis, 420 mm for the Y-axis, and 400 mm for the Z-axis.

What type of spindle taper does the machine use?

The machine uses an MT4 taper for vertical operations and an NT40 taper for horizontal operations.

Is the voltage of the machine adjustable?

Yes, the machine operates at a voltage of 380V, which can be customized as needed.

What is the size of the machine's table?

The size of the machine's table is 1370 x 305 mm.

What are the key features of the X6330 milling machine?

Key features include a high-quality gear head design, multifunctional capabilities, precise table travel, flexible spindle speeds, and robust construction.

Who would benefit from using the X6330 milling machine?

It is ideal for professional workshops, small fabrication shops, and educational institutions for technical training purposes.

Can the milling head rotate, and if so, what are the limits?

Yes, the milling head can rotate 90° left and right, and 45° back and forth.

What types of projects is this machine suitable for?

The X6330 is suitable for precision machining in metalworking, fabricating parts in engineering projects, and small to medium production runs.

What is the spindle motor power for this milling machine?

The spindle motor power is 2.2KW for vertical operations and 3.7KW for horizontal operations.

What is the pitch and width of the T-Slots on the machine?

The machine has 3 T-slots that are 16 mm wide with a pitch of 65 mm.
