Woodworking machinery wood band sawmill machine — image 1

Woodworking machinery wood band sawmill machine
Woodworking Machinery

Woodworking machinery wood band sawmill machine

  • SKU: 1601161176027
  • Category: Woodworking Machinery

Product Description

R575,899

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options
Section:
Machinery
SKU:
1601161176027
Payment security and privacy badges

Product Description

Product Description

Combined with the current automatic technology,the heavy duty horizontal band saw machine is a high quality product developed by the company with 30 years of production experience.It solves the difficulty of sawing large diameter wood in the past and supplies for national patents.A great many products are exported to Gabon,Angola,Fiji and Sountheast Asian countries

Heavy Duty (Large Scale) Horizontal Band Saw
Max Sawing Wood Width1200MM1500MM2000MM2500MM
Distance Between Saw Blade And Saw Bed1100MM1200MM1700MM2200MM
Saw wheel diameter960MM1000MM1070MM1070MM
Max Sawing thickness350MM350MM400MM400MM
Sawing wood Length6Meters6Meters6Meters6Meters
Saw Blade Length7700MM8600MM9300MM10500MM
Saw Wheel Motor Power30KW37KW45KW55KW
Other Motor3KW*1For forward/backward,1.5KW*1For Blade Tension,2.2KW*1For Up/down Sizing
Weight3800KG4500KG5000KG5500KG
Option 1: Change For 60HP  Four Cylinder diesel Engine
Option 2:Add Money Of Per Meter For Add Rail Frame for easy move around in different places .







Diesel Large Size Horizontal Band Saw





Detailed Images




4 Stand columns and precision screw

make sure up and down the saw wheel

 stable and accurate.






Turning,cylindrical grinding,chroming makes sure the stand columns is smooth and precision.Copper sliding bush is wear-resisting.






Taiwan FATEK PLC central touch screen panel,circuitry concentrating on the control panel,control the sawing thickness digitally.








Central saw wheel design makes the saw wheel running stable,extend the working life,and reduce the probability of band saw blade break down.





Counterweight steel makes the blades more flexible and not easy to break.





Variable Frequency speed adjustable forward/backward, The forward speed will be 1-20Meters/Minute



Carbide Band Saw Blade





Frequently Asked Questions

What is the maximum sawing width of the wood band sawmill machine?

The maximum sawing wood width for this machine is available in options of 1200MM, 1500MM, 2000MM, and 2500MM.

How thick can the machine saw wood?

The maximum sawing thickness for the wood band sawmill machine is 350MM for the smaller models and 400MM for the larger models.

What is the weight of the wood band sawmill machine?

The weight of the machine varies by model, ranging from 3800KG to 5500KG.

What kind of motor power does the saw wheel use?

The saw wheel motor power options include 30KW, 37KW, 45KW, and 55KW depending on the model.

Does the machine come with options for additional features?

Yes, there are options to change to a 60HP four-cylinder diesel engine and to add rail frames for easier movement.

What materials can be cut with this sawmill machine?

This sawmill machine is designed primarily for cutting large diameter wood.

Is the operation of the sawmill machine automated?

Yes, the wood band sawmill machine incorporates current automatic technology for enhanced operation.

How long is the saw blade?

The saw blade length varies by model, with options ranging from 7700MM to 10500MM.

What is the maximum sawing wood length supported by the machine?

The maximum sawing wood length supported by this machine is 6 meters.

How does the machine ensure stable operation?

The machine features four stand columns and precision screws to ensure the saw wheel operates stably and accurately.

Can the sawing thickness be adjusted?

Yes, the sawing thickness can be controlled digitally via a central touch screen panel.

What is the speed range for the machine's forward operation?

The forward speed of the machine is adjustable from 1 to 20 meters per minute.

Where are these machines exported to?

These machines are exported to countries including Gabon, Angola, Fiji, and various Southeast Asian countries.

What type of blade does the machine use?

The machine uses a carbide band saw blade, which is designed for durability and efficiency.

What additional features enhance the blade's performance?

The machine includes counterweight steel to make the blades more flexible and reduce the likelihood of breakage.
