The Water Tank Type Wire Drawing Machine is designed for high efficiency and precision. It is perfect for drawing wires with various diameters. This machine is automatic, making it easy to use and ideal for production lines. With a robust design and advanced features, i...
Select a product option to continue.
Explore funding with Afrimart's partners. Subject to provider approval.
The Water Tank Type Wire Drawing Machine is designed for high efficiency and precision. It is perfect for drawing wires with various diameters. This machine is automatic, making it easy to use and ideal for production lines. With a robust design and advanced features, it ensures quality output and reliable performance.
| Attribute | Details |
|---|---|
| Speed | 100-300 m/min |
| Diameter of Block | 350-600 mm |
| Inlet Diameter | 1.5-10 mm |
| Outlet Diameter | 0.8-5.5 mm |
| Power | 15-18.5 kW |
| Warranty | 1 Year |
| Production Capacity | 30 sets per month |
| After-sales Service | Engineers available to service machinery overseas |
| Color | Blue or customized |
| Dimensions (L*W*H) | 2400*1100*1100 mm |
| Type | LT1-12/350 Water-tank |
| Dia. Of Coiling Block | φ350mm |
| Wire Drawing Mould | 12pcs |
| Dia. Of Inlet Wire | φ2.2mm |
| Min. Dia. Of Outlet Wire | φ0.7mm |
| Total Condensation | 86% |
| Average Condensation | 16% |
| Speed Of Drawing | 250-400m/min |
| Power Of Motor | 15-18.5kw |
| Dimension | 2400×1100×1100mm |
| Weight | 1800kg |
| Type | LT1-19/200 Water-tank |
| Dia. Of Coiling Block | φ200mm |
| Wire Drawing Mould | 19pcs |
| Max. Dia. Of Inlet Wire | φ1.6mm |
| Min. Dia. Of Outlet Wire | φ0.3mm |
| Total Condensation | ~96% |
| Average Condensation | ~15.5% |
| Speed Of Coiling Block | 400~700m/min |
| Power Of Motor | YCT250-4/22kw |
| Dimension | 2310×1440×1160mm |
| Weight | ~4000kg |
| Type | LHT-20/280 Water-tank |
| Max. Dia. Of Inlet Wire | 3.0mm |
| Min. Dia Of Outlet Wire | 0.35mm |
| Speed Of Drawing | 900m/min |
| Wire Drawing Mould | 19pcs |
| Cone Pulley | 4pcs |
| Dia. Of Capstan | 16% |
| Max. Size Of Spool | 250-400m/min |
| Power Of Drawing Wire | 30-37.5kw |
| Power Of Spooling Motor | YLJI32-25N.m/4 n=1250rpm |
| Dimension | 6500×1800×1600mm |
| Weight | 5000kg |
| Name | Model | Range of Dia. |
| Discharging Machine | ||
| Pointing Machine | F-96 | 6.5-1.5mm |
| Pointing Machine | F-80 | 3.5-1.0mm |
| Butt-Welding Machine | UN-10 | 8--2mm |
| Butt-Welding Machine | UN-3 | 6.5-1.5mm |
| Butt-Welding Machine | UN-1 | 3.5-1.0mm |
| Automatic Discharging Machine | XB-600 | capacity 800kg |
| Automatic Discharging Machine | XB-360 | capacity 400kg |
| I Type Spool Reeling Machine | SG-800 | capacity 800kg |
| I Type Spool Reeling Machine | SG-630 | capacity 500kg |
| Descaling Machine | SW650 | |
| Motorless Descaling Machine | with steel brush | |
| Well Type Furnace | RJ-90-9 |
| Speed | 100-300 m/min |
|---|---|
| Diameter of Block | 350-600 mm |
| Inlet Diameter | 1.5-10 mm |
| Outlet Diameter | 0.8-5.5 mm |
| Power | 15-18.5 kW |
| Warranty | 1 Year |
| Production Capacity | 30 sets per month |
| After-sales Service | Engineers available to service machinery overseas |
| Color | Blue or customized |
| Dimensions (L*W*H) | 2400*1100*1100 mm |
| Dia. Of Inlet Wire | φ2.2mm |
| Speed Of Coiling Block | 400~700m/min |
| Min. Dia Of Outlet Wire | 0.35mm |
| Cone Pulley | 4pcs |
| Dia. Of Capstan | 16% |
| Max. Size Of Spool | 250-400m/min |
| Power Of Drawing Wire | 30-37.5kw |
| Power Of Spooling Motor | YLJI32-25N.m/4 n=1250rpm |
The maximum inlet wire diameter that this machine can handle is 3.0 mm.
The machine operates at a speed range of 100 to 900 m/min, depending on the specific model and application.
Yes, it is designed for high efficiency and can produce up to 30 sets per month, making it suitable for large production volumes.
The machine requires between 15 to 37.5 kW of power, depending on the model.
Yes, the Water Tank Type Wire Drawing Machine is available in blue or can be customized in other colors as per customer specifications.
It can produce various types of wires including electrical wires, cables for construction, metal wires for automotive parts, and telecommunications wires.
The machine comes with a warranty period of 1 year.
The dimensions of the machine are 2400 mm (L) x 1100 mm (W) x 1100 mm (H).
Yes, engineers are available to provide after-sales service and support for the machinery overseas.
The average condensation rate is approximately 16% for most applications.
The machine weighs approximately 1800 kg.
Yes, it is suitable for a wide range of industrial applications, including manufacturing, automotive, and telecommunications.
Regular maintenance includes checking and replacing worn components, ensuring proper lubrication, and keeping the machine clean for optimal performance.
The production capacity of the Water Tank Type Wire Drawing Machine is 30 sets per month.
Yes, the Water Tank Type Wire Drawing Machine features automatic operation for ease of use and improved efficiency.
