WADLEY Cylinder Boring And Surface Milling Machine
- Section : Machinery
- Category : Machine Tool Equipment
- SKU : 1601126404365
WADLEY Cylinder Boring And Surface Milling Machine
The WADLEY Cylinder Boring and Surface Milling Machine is a high-precision machine designed for versatile metal processing tasks. With its ability to handle both boring and milling operations, this machine is perfect for industries requiring efficient and accurate machining of engine components, including cylinders and other critical parts. Its sturdy construction and advanced features make it a reliable choice for high-performance machining in industrial settings.
Key Features:
4-Axis Control: The WADLEY machine features 4-axis control, enabling precise movements and versatility in machining tasks. This configuration ensures smooth and accurate operations during both boring and surface milling.
Spindle Speed Range: The spindle speed ranges from 53 to 840 rpm, offering flexibility for different machining needs. This range ensures effective material removal for a variety of workpieces and applications.
Spindle Motor Power: Powered by a 3 kW spindle motor, this machine provides ample power for tough metalworking tasks, ensuring efficient and consistent machining performance.
Max. Boring Depth: The machine is capable of reaching a maximum boring depth of 500 mm, making it suitable for a wide range of cylinder sizes and other components that require deep boring operations.
Boring Diameter: The WADLEY machine can accommodate a boring diameter from 35 to 200 mm, offering great flexibility for various machining jobs.
Spindle Feed Range: The adjustable spindle feed ranges from 0.05 to 0.20 mm/rev, allowing for precise control over the cutting process, which is critical for achieving the required tolerances.
High-Precision Performance: With positioning accuracy of 0.04 mm on the X, Y, and Z axes, the WADLEY machine ensures that each part is machined to exact specifications, delivering high-precision results.
Table Travel: The table cross travel is 100 mm, and the longitudinal travel reaches 900 mm, providing ample space for larger workpieces and ensuring stable movement during machining.
Sturdy Construction: Weighing 6 tons, the machine is built for stability, ensuring minimal vibration and high-precision results, even during heavy-duty operations.
Production Capacity: The machine has a production capacity of 50 sets per month, making it ideal for both small and large-scale production environments.
Voltage: The machine is designed to operate on a 380V/220V power supply, making it suitable for industrial use.
Inspection and Test Reports: The WADLEY Cylinder Boring and Surface Milling Machine comes with a video outgoing inspection and machinery test report to ensure it meets high-quality standards before delivery.
Conclusion:
The WADLEY Cylinder Boring and Surface Milling Machine is a robust and versatile solution for metal processing. Its advanced 4-axis control, high-precision performance, and powerful spindle motor make it a reliable choice for industries requiring efficient and accurate boring and milling operations. With its large working range, adjustable spindle feed, and reliable construction, the WADLEY machine is an essential tool for any workshop focused on metalworking and engine repair.
Product Info Gallery
Right elevation
Left elevation
PRODUCT SPECIFICATIONS
| No | Model | T8018A | T8018B | T8018C |
| 1 | Boring Diameter（mm） | 30-180 | 30-180 | 42-180 |
| 2 | Max boring depth(mm） | 450 | 450 | 650 |
| 3 | Table size(mm) | 1200*500 | 1200*500 | 1680*450 |
| 4 | Spindle feed（mm） | 0.05,0.1,0.2 | 0.05,0.1,0.2 | 0.05,0.1,0.2 |
| 5 | Power(kw) | 3.75 | 3.75 | 3.75 |
| 5 | The rotation speed of spindle（mm） | 140-610 | 175,230,300,350,460,500 | 175,230,300,350,460,500 |
| 6 | Overall Dimensions(mm) | 2000*1240*1920 | 2000*1240*1920 | 2680*1500*2350 |
| 7 | N.W/G.W(kg) | 2000/2200 | 2000/2200 | 3500/3700 |
