Vertical Machining Center Model-VMC1160

The Vertical Machining Center Model-VMC1160 is primarily used for precision machining of metals, plastics, and other materials in various industries, including aerospace, automotive, and manufacturing.

The key specifications include a spindle speed of up to 10,000 RPM, a working table size of 1,200 mm x 600 mm, and a maximum load capacity of 800 kg.

Yes, the VMC1160 is designed for both small and large-scale production, offering high precision and efficiency suitable for mass manufacturing.

The VMC1160 is equipped with a user-friendly CNC control system that supports various programming languages, making it easy to operate and integrate into existing workflows.

The VMC1160 is compatible with a wide range of tooling options, including end mills, drills, and taps, depending on the specific machining requirements.

The VMC1160 has an average power consumption of approximately 15 kW, depending on the operational load and machining conditions.

The maximum travel distance is 1,100 mm on the X-axis, 600 mm on the Y-axis, and 600 mm on the Z-axis.

Yes, the VMC1160 typically comes with a standard warranty that covers parts and labor for a specified period. Please check with your supplier for specific warranty details.

The VMC1160 is equipped with several safety features, including emergency stop buttons, safety interlocks, and protective guards to ensure operator safety.

Yes, the VMC1160 can be customized with various optional features and attachments to meet specific machining requirements.

Regular maintenance is recommended every 500 operating hours, including lubrication, inspection of components, and software updates.

Yes, training is often provided by the supplier or manufacturer to ensure operators are proficient in using the VMC1160 safely and effectively.

The cost of the VMC1160 can vary based on features and configurations, but it typically falls within the range of $50,000 to $100,000.

The VMC1160 can be purchased through authorized dealers, online machinery marketplaces, or directly from the manufacturer.

Post-purchase support includes technical assistance, maintenance services, and access to spare parts through the manufacturer or authorized dealers.
