Universal cnc-lathe TCK56D-500 metal slant bed lathe hight equipment
Select a product option to continue.
Asset Finance Available
Check Funding Options
Explore funding with Afrimart's partners. Subject to provider approval.
Product Description
Product Descriptions
Overview
Product Description
| Projects | Units | Specifications | Remarks | |||||
| Maximum turning diameter | mm | 560 | ||||||
| on bed | ||||||||
| Maximum cutting length | mm | 500 | ||||||
| Standard cutting diameter | mm | 280 | Taiwan 8 station | |||||
| Maximum cutting diameter | mm | 350 | ||||||
| Standard cutting diameter | mm | 210 | Taiwan 12 stations | |||||
| Maximum cutting diameter | mm | 280 | ||||||
| Maximum turning diameter | mm | 350 | ||||||
| on a skateboard | ||||||||
| Spindle end type and code | A2-6 | Integral spindle | ||||||
| unit | ||||||||
| Main shaft hole diameter | mm | 65 | ||||||
| Maximum pass bar diameter | mm | 50 | ||||||
| Headstock | Spindle speed | r/min | 50 to 4500 | |||||
| range | ||||||||
| Maximum spindle | Nm | 177 | ||||||
| output torque | ||||||||
| Spindle speed | Stepless speed change | |||||||
| series | ||||||||
| Main motor | kW | 15 (15 minutes) /11 (rated) | ||||||
| output power | ||||||||
| Chuck | Chuck | mm | 8” | |||||
| diameter/type | ||||||||
| X-axis fast shift speed | m/min | 30 | ||||||
| Z-axis fast shift speed | m/min | 30 | ||||||
| X-axis stroke | mm | 200 | ||||||
| Z-axis stroke | mm | 560 | ||||||
| Overall tailseat stroke | 450 | |||||||
| Tailstock sleeve cone | Mohs | 5# | ||||||
| hole taper | ||||||||
Frequently Asked Questions
What is the maximum turning diameter of the TCK56D-500 lathe?
The maximum turning diameter on the bed is 560 mm.
What is the maximum cutting length of the TCK56D-500?
The maximum cutting length is 500 mm.
How many stations does the lathe have?
The TCK56D-500 features a Taiwan 8 station tool turret as standard.
What type of spindle does the TCK56D-500 use?
The lathe uses an A2-6 integral spindle unit.
What is the spindle speed range of the TCK56D-500?
The spindle speed ranges from 50 to 4500 revolutions per minute (r/min).
What is the output power of the main motor?
The main motor has an output power of 15 kW for 15 minutes and 11 kW rated.
What is the chuck size on the TCK56D-500?
The chuck diameter is 8 inches.
What are the fast shift speeds for the X and Z axes?
The X-axis fast shift speed is 30 m/min and the Z-axis fast shift speed is also 30 m/min.
What is the tailstock sleeve cone type?
The tailstock sleeve cone type is Mohs 5# hole taper.
What is the maximum pass bar diameter for this lathe?
The maximum pass bar diameter is 50 mm.
Is the spindle speed adjustable?
Yes, the spindle speed features a stepless speed change series for flexible operation.
What are the stroke lengths for the X and Z axes?
The X-axis stroke is 200 mm and the Z-axis stroke is 560 mm.
What is the overall tailseat stroke of the lathe?
The overall tailseat stroke is 450 mm.
Does the TCK56D-500 come with any warranty?
Warranty details may vary, please check with the seller for specific warranty information.
What are the applications for the TCK56D-500 lathe?
The TCK56D-500 is suitable for various metalworking applications including precision machining, turning, and fabrication.
