Top PLE350 Crawler Hydraulic Water Well Drilling Rig DTH 350M Portable Drilling Rig Machine with Dual Use
Asset finance available
Do you want funding for this equipment?
Afrimart can connect you with trusted funding partners who specialise in asset finance for businesses like yours. Compare options and apply in minutes — final approval is subject to provider review.
Check funding options
Secure & no obligation
- Section : Machinery
- Category : Drilling Rigs
- SKU : 1601920943646
Top PLE350 Crawler Hydraulic Water Well Drilling Rig DTH 350M Portable Drilling Rig Machine with Dual Use
The Top PLE350 Crawler Hydraulic Water Well Drilling Rig DTH 350M Portable Drilling Rig Machine with Dual Use is a powerful machine for drilling water wells. It can drill deep into the ground to reach water. This rig is easy to operate and moves on crawler tracks. It works well in many different places. The Top PLE350 Crawler Hydraulic Water Well Drilling Rig DTH 350M Portable Drilling Rig Machine with Dual Use is a great choice for your drilling jobs.
Specifications
| Attribute | Details |
|---|---|
| Product Name | Water Well Drilling Rig |
| Type | Water Well Drilling Rig |
| Usage | Water Well |
| Drilling Depth | 200m, 260m, 350m, 600m |
| Drilling Diameter | 110–305 mm |
| Power Type | Diesel |
| Voltage | 380 V |
| Engine Type | Diesel Engine |
| Core Components | Pump, Engine, Gear, Bearing |
| Drill Pipe Diameter | 76 / 89 / 102 / 114 mm |
| Drill Head Lift Force | 160 / 180 / 260 / 300 kN |
| Drill Head Feed Stroke | 3300 / 6600 mm |
| Air Consumption | 1.7–2.5 Mpa |
| Mud Pump Flow Rate | 160 m³/h, 250 m³/h |
| Mobility | Crawler |
| Crawler Type | Rubber tracks / Steel tracks |
| Dimension (L×W×H) | 3600 × 1700 × 2300 mm |
| Weight | 4000 KG |
| Brand Name | pailien |
| Certification | CE / ISO9001 |
| Warranty | 1.5 year |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Key Selling Points | Easy To Operate |
| After-Sales Service | 24/7 online video guidance |
| Free Replacement Parts |
