Product Show
spider crane
Hydraulic outriggers take up less space when working, and the outriggers can also be adjusted . Crawler chassis, more stable,suitable for difficult and complex working environment.
Product Details
Every detail is customized for you, colors, logo, engine...
safe load indicator, remote control can be optional
Engine is optional
Yanmar 3TNV88F EPA Tier4
Changchai 3M78 Euro5
optional
Vacuum glass lifter and hanging basket can be optional
details
We will do every detail for you
customized for you
fly jib
one key outrigger
Electric proportional control valve
The fly jib can be added
(1.5m*3 sections, full extension length 3m)
Max working radius
12.5m*0.2Ton
Max Ground Lifting Height
14m
Outrigger Max extended dimensions
4470mm 3940mm
Product Paramenters
| Specification | 2.95 Ton |
| Maximum working radius | 7.8m×0.2Ton |
| Maximum ground lift | 9.2mX0.8Ton |
| Engine Producer | YARMAR |
| Type/displacement | EV80/F195 |
| Start method | Electric start |
| Startup performance | -5°C~40°C |
| Fuel volume | Diesel/8L |
| Battery capacity | 12v 45AH |
| Fuel consumption | 274g/kW-h |
| Noise level | Rated speed≤81.5dBA (1m) |
| Emission Standards | CE/EPA/Ero5 |
| Winch Hook up speed | 0-8m/min |
| Winch Wire Rope Specifications | Φ8mm×45m |
| Telescopic device Boom form | 5-section boom, U-shaped high-strength manganese |
| Boom length/time | 2.8m-8.2m/22sec |
| Boom angle/time | 0-75°/13sec |
| Rotation angle/speed | 0-360°（continuous）/60sec |
| Outrigger Action Form | Manual unscrewing + hydraulic automatic support (two legs) |
| Maximum extension (mm) | 4010 (long) X3260 (rear), (front) |
| Way of traveling | Hydraulic motor drive, two-speed |
| Traveling speed | 0-2.5km/h |
| Traveling Gradeability | 20°(36%) |
| Voltage of motor | AC380V |
| Type of operation (jib/outrigger), manual travel | Manual operation, manual walking + remote control (optional) |
| The standard configuration | Diesel engine and electric motor (dual power) |
| Vehicle size | Length 2830*width 800*height 1650 |
| Craftsmanship | Paint assembly process |
| Maximum working radius | 7.8m×0.2Ton |
|---|---|
| Maximum ground lift | 9.2mX0.8Ton |
| Engine Producer | YARMAR |
| Type/displacement | EV80/F195 |
| Start method | Electric start |
| Startup performance | -5°C~40°C |
| Fuel volume | Diesel/8L |
| Battery capacity | 12v 45AH |
| Fuel consumption | 274g/kW-h |
| Noise level | Rated speed≤81.5dBA (1m) |
| Emission Standards | CE/EPA/Ero5 |
| Winch Hook up speed | 0-8m/min |
| Winch Wire Rope Specifications | Φ8mm×45m |
| Telescopic device Boom form | 5-section boom, U-shaped high-strength manganese |
| Boom length/time | 2.8m-8.2m/22sec |
| Boom angle/time | 0-75°/13sec |
| Rotation angle/speed | 0-360°（continuous）/60sec |
| Outrigger Action Form | Manual unscrewing + hydraulic automatic support (two legs) |
| Maximum extension (mm) | 4010 (long) X3260 (rear), (front) |
| Way of traveling | Hydraulic motor drive, two-speed |
| Traveling speed | 0-2.5km/h |
| Traveling Gradeability | 20°(36%) |
| Voltage of motor | AC380V |
| Type of operation (jib/outrigger), manual travel | Manual operation, manual walking + remote control (optional) |
| The standard configuration | Diesel engine and electric motor (dual power) |
| Vehicle size | Length 2830*width 800*height 1650 |
| Craftsmanship | Paint assembly process |
The Tonlita track spider crane has a maximum ground lifting height of 14 meters.
The crane can be equipped with a Yanmar 3TNV88F EPA Tier4 engine or a Changchai 3M78 Euro5 engine, both of which are optional.
The maximum working radius of the Tonlita track spider crane is 12.5 meters with a load capacity of 0.2 tons.
Yes, the Tonlita track spider crane can be operated with an optional remote control for convenience.
The maximum extended dimensions of the outriggers are 4470mm at the rear and 3940mm at the front.
Yes, the crawler chassis design provides enhanced stability, making it suitable for difficult and complex working environments.
The crane has a rated noise level of ≤81.5 dBA at 1 meter.
Yes, every detail of the Tonlita track spider crane can be customized, including colors, logos, and engine options.
The Tonlita track spider crane has a traveling speed of 0-2.5 km/h.
The fuel consumption of the crane is approximately 274g/kW-h.
Optional accessories include a vacuum glass lifter and a hanging basket.
The standard configuration includes a diesel engine and an electric motor, providing dual power options.
The crane features a 5-section boom with a length ranging from 2.8m to 8.2m, and it can extend fully in 22 seconds.
The outrigger system operates using manual unscrewing combined with hydraulic automatic support for stability.
The crane is equipped with a 12v 45AH battery.
