Small Diamond Drill Rig Rock Sampling Core Drilling Rig
Asset finance available
Do you want funding for this equipment?
Afrimart can connect you with trusted funding partners who specialise in asset finance for businesses like yours. Compare options and apply in minutes — final approval is subject to provider review.
Check funding options
Secure & no obligation
- Section : Machinery
- Category : Drilling Rigs
- SKU : 1600301463734
Small Diamond Drill Rig Rock Sampling Core Drilling Rig
The Small Diamond Drill Rig Rock Sampling Core Drilling Rig is a strong and portable machine. It helps you drill deep into the ground to collect rock samples. This rig works well for many jobs. It uses a diesel engine and runs on 380V power. It can drill up to 500 meters deep! This makes it great for mining and construction work.
This Small Diamond Drill Rig Rock Sampling Core Drilling Rig comes with a pump and engine as its main parts. It is easy to move around because it is portable. The rig weighs 750 KG and has a compact size of 1070x1030x1270 mm. It also comes with a 1-year warranty. You can get video technical support and online help if you need it.
Specifications
| Attribute | Details |
|---|---|
| Type | Core Drilling Rig |
| Usage | Ore |
| Drilling Depth | Max. 500m |
| Drilling Diameter | 75mm, 100mm, 200mm |
| Power Type | Diesel |
| Voltage | 380V |
| Core Components | Pump, Engine |
| Key Selling Points | Competitive Price |
| Weight | 750 KG |
| Brand Name | Glorytek |
| Dimension (L*W*H) | 1070x1030x1270 mm |
| Mobility | Portable |
| Drilling Depth (Options) | 300/250/150/100/80m |
| Initial Hole Diameter | 75/91/110/130/150mm |
| Drill Rod Diameter | 50mm |
| Angle Range | 75°-90° |
| Weight (without power unit) | 750kg |
| Distance from a Drilling Hole | 300mm |
| Spindle Speed Forward | 85/125/230/375/560/1000 r/min |
| Spindle Stroke | 450mm |
| Spindle Lifting Capacity | Max 45 KN |
| Spindle Pull-down | Max 39KN |
| Applicable Industries | Construction works, Energy & Mining |
| Condition | New |
| Certification | ISO |
