Small Business 50L 100L Vacuum Homogenizer Emulsifier Mixer Machine for Making Cream,Mascara,Nail Polish,Liquid foundation

SKU: 1600158392916
Category: Mixing Equipment

R855,000

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Mixing Equipment
SKU:: 1600158392916

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

09 Nov, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

Lifting Small Vacuum Mixer：

This machine mainly consist of water pot, oil pot, emulsifying pot, vacuum system, lifting system, electric control system, operation platform, etc. (Systems and structure can be customized according to customer’s requirements.)

This kind of vacuum emulsifying cosmetic cream mixer makes use of the high shear emulsifier to distribute one or several phases to another continuous phase rapidly and evenly. It is mainly applied in such industries as daily skin care products (Body butters, face creams, hand lotions, detergents, etc.), biopharmaceutical industry, food industry, paint and ink, nanometer materials, petrochemical industry, printing and dyeing auxiliaries, pulp & paper, pesticide, fertilizer, plastic & rubber, electrics and electronics, fine chemical industry, etc. The emulsifying effect is more prominent for materials of high base viscosity and high solid content.

Specification

Type	Hydraulic Lifting
Material	SUS316L for all contact parts and SUS304 for external
Mixing	Siemens motor + reducer DELTA inverter
Bottom homogenizer	0-3600rpm
Discharging way	Button discharge/Manual discharge

Details Images

Lip Parts

Seal head: SUS316L, thick: 4mm
Material filter, vacuum pressure meter, vacuum discharge valve, vacuum inlet, positive pressure inlet, CIP system (Spray ball),
sight glass light, sight window, man-hole, hopper

Electric control system

Can be customized to PLC+ Touch screen
Outer layer material: adopt SUS304 Stainless steel plate, thickness:1.5mm
Meter: thermometer, Time digital display met, voltmeter, Homogenizer time reply
Button: Each function switch control button, emergency switch, light switch, start/stop buttons
Indicate Light: RYG 3 colors indicate light and all system working indicate
The electrical components: include various control relay

Stainless Steel Sanitary Grade Pipes

Material: SUS316L and SUS304, soft tubes
Valve: Manual valves (can be customized to pneumatic valves)
Pure water pipe, tap-water pipe, drain pipe, steam pipe (customized) etc.

Homogenizer

Bottom Homogenizer (can be customized to upper homogenizer)

Material: SUS316L
Motor power: 2KW
Speed: 0-3600rpm, DELTA inverter
Processing methods: Rotor and stator adopts wire-cutting finish machining, polishing treatment before assembly

Stirrer paddle & scraper blade

Frame oar wall single way scrapping mixing (can be customized to double way mixing, circulation mixing etc.)
Stirrer paddle: SUS316L, thick: 10mm
Scraper blade: PTFE material, thick: 15mm, white
Motor power: 1.5KW
Speed: 0-75rpm, DELTA inverter
Adopting Germany Bergman mechanical seal, NSK bearing made in Japan

Water and oil pot

Material: SUS316L and SUS304
Layer: 3 layers for double jacket for electric heating (can be customized to steam heating)
Open lid

Frequently Asked Questions

What is the maximum capacity of the vacuum homogenizer?

The vacuum homogenizer is available in two capacities: 50L and 100L.

What materials can be processed with this machine?

This machine can process a variety of materials including cosmetic creams, mascara, nail polish, liquid foundation, and is also suitable for food products, biopharmaceuticals, paints, inks, and more.

Is the machine customizable?

Yes, the systems and structure of the vacuum homogenizer can be customized according to customer requirements.

What type of motor does the mixer use?

The mixer uses a Siemens motor combined with a DELTA inverter for efficient operation.

What are the main components of the vacuum homogenizer?

The main components include a water pot, oil pot, emulsifying pot, vacuum system, lifting system, electric control system, and operation platform.

What is the emulsifying effect of this machine like?

The emulsifying effect is particularly strong for materials with high base viscosity and high solid content.

What materials are used in the construction of the machine?

The contact parts are made of SUS316L stainless steel, while the external parts are made of SUS304 stainless steel.

How is the discharge of the mixture handled?

The machine features both button discharge and manual discharge options for convenience.

What safety features does the machine include?

Safety features include an emergency switch, light switch, and various control relay components.

Can the electric control system be customized?

Yes, the electric control system can be customized to include a PLC and touch screen interface.

What is the speed range of the bottom homogenizer?

The bottom homogenizer operates at a speed range of 0-3600 RPM.

What type of heating options are available for the water and oil pots?

The water and oil pots can be heated electrically or customized for steam heating.

What is the purpose of the scraper blade?

The scraper blade is designed to enhance mixing efficiency by ensuring that all materials are adequately mixed and that the vessel walls are cleaned during operation.

Is there a warranty included with the machine?

Warranty details may vary, so please check with the manufacturer or supplier for specific warranty information.

How is the machine maintained?

Regular maintenance involves cleaning the components, checking for wear and tear, and ensuring that all systems are functioning properly. Specific maintenance guidelines will be provided with the machine.
