Products Description
Small ball mill for mini sand rock gold crushing and grinding

Ball mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc. Besides,it can grind various ores and other materials with dry type and wet type. There are two kinds of ball mill, grate type and overflow type due to different ways of discharging material.

Features
♦ Energy-saving.
♦ Simple structure and split installation
♦ Easy to installing and maintaining
♦ Two types feeders: combined feeder and cylinder feeder
♦ Dry ball mills & wet ball mills for option according to different materials & discharging methods

Working Principle
Ball Mill is a type of ore milling machine used to grind materials into an extremely fine powder, mainly used in the mineral ore processing industry. Ball Mill could grind various ores and other materials either wet or dry, depending on requirements. It consists of a large cylinder which slowly rotates around a horizontal axis. The cylinder is partially filled with the material to be grind, plus the grinding media (steel grinding balls). Inside the cylinder, the media will be lifted to a certain height under the action of centrifugal force and then drop or fall, grinding the ore in between the balls as they interact. Feed material to be ground enters the cylinder via a hopper on one end and after being crushed by the grinding medium is discharged at the other end



Product Parameter
| Model | Shell rotation speed(r/min) | Ball load(t) | Feeding size(mm) | Discharging size(mm) | Capacity(t/h) | Motor power(kw) | Weight(t) |
| Ø900*1800 | 36-38 | 1.5 | <=20 | 0.075-0.89 | 0.65-2 | 18.5 | 4.6 |
| Ø900*3000 | 36 | 2.7 | <=20 | 0.075-0.89 | 1.1-3.5 | 22 | 5.6 |
| Ø1200*2400 | 36 | 3 | <=25 | 0.075-0.6 | 1.5-4.8 | 30 | 12 |
| Ø1200*3000 | 36 | 3.5 | <=25 | 0.074-0.4 | 1.6-5 | 37 | 12.8 |
| Ø1200*4500 | 32.4 | 5 | <=25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
| Ø1500*3000 | 29.7 | 7.5 | <=25 | 0.074-0.4 | 2-5 | 75 | 15.6 |
| Ø1500*4500 | 27 | 11 | <=25 | 0.074-0.4 | 3-6 | 110 | 21 |
| Ø1500*5700 | 28 | 12 | <=25 | 0.074-0.4 | 3.5-6 | 130 | 24.7 |
| Ø1830*3000 | 25.4 | 11 | <=25 | 0.074-0.4 | 4-10 | 130 | 28 |
| Ø1830*4500 | 25.4 | 15 | <=25 | 0.074-0.4 | 4.5-12 | 155 | 32 |
| Ø1830*6400 | 24.1 | 21 | <=25 | 0.074-0.4 | 6.5-15 | 210 | 34 |
| Ø1830*7000 | 24.1 | 23 | <=25 | 0.074-0.4 | 7.5-17 | 245 | 36 |
| Ø2100*3000 | 23.7 | 15 | <=25 | 0.074-0.4 | 6.5-36 | 155 | 34 |
| Ø2100*4500 | 23.7 | 24 | <=25 | 0.074-0.4 | 8-43 | 245 | 42 |
| Ø2100*7000 | 23.7 | 26 | <=25 | 0.074-0.4 | 8-48 | 280 | 50 |
| Ø2200*4500 | 21.5 | 27 | <=25 | 0.074-0.4 | 9-45 | 280 | 48.5 |
| Ø2200*6500 | 21.7 | 35 | <=25 | 0.074-0.4 | 14-26 | 380 | 52.8 |
| Ø2200*7000 | 21.7 | 35 | <=25 | 0.074-0.4 | 15-28 | 380 | 54 |
| Ø2200*7500 | 21.7 | 35 | <=25 | 0.074-0.4 | 15-30 | 380 | 56 |
| Ø2400*3000 | 21 | 23 | <=25 | 0.074-0.4 | 7-50 | 245 | 54 |
| Ø2400*4500 | 21 | 30 | <=25 | 0.074-0.4 | 8.5-60 | 320 | 65 |
| Ø2700*4000 | 20.7 | 40 | <=25 | 0.074-0.4 | 12-80 | 400 | 94 |
| Ø2700*4500 | 20.7 | 48 | <=25 | 0.074-0.4 | 12-90 | 430 | 102 |
| Ø3200*4500 | 18 | 65 | <=25 | 0.074-0.4 | ----- | 800 | 137 |
Applications
* Mining Industry : Used to grind various kinds of ores.
* Ceramic Industry : Used to finish and grind various kinds of raw materials and cement.
* Smelting Industry : Used to grind various kinds of slag.
* Power generation : Used to grind coal for combustion use.
* Chemical Industry : Used to grind coke, ilmenite, and others.
]

| combined feeder and cylinder feeder | |
| * Mining Industry | Used to grind various kinds of ores. |
| * Ceramic Industry | Used to finish and grind various kinds of raw materials and cement. |
| * Smelting Industry | Used to grind various kinds of slag. |
| * Power generation | Used to grind coal for combustion use. |
| * Chemical Industry | Used to grind coke, ilmenite, and others. |
A small ball mill is primarily used for crushing and grinding materials, specifically in the mining and mineral processing industries. It can grind various ores and materials into an extremely fine powder.
This ball mill can process a wide range of materials, including ores, cement, silicate, refractory materials, fertilizers, and glass ceramics. It can handle both dry and wet materials.
The two types of ball mills available are grate type and overflow type, which differ based on their material discharging mechanisms.
The ball mill operates by rotating a large cylinder filled with the material to be ground along with grinding media, like steel balls. As it rotates, the media is lifted and dropped, grinding the material through impact.
Yes, the small ball mill is designed to be energy-saving, optimizing power consumption while achieving effective grinding results.
The ball mill features a simple structure and split installation, making it easy to install and maintain.
The capacity of the small ball mill varies depending on the model, ranging from approximately 0.65 to 800 tons per hour.
The motor power for the ball mill varies by model, with options ranging from about 4.6 kW to 800 kW.
Yes, the small ball mill is suitable for processing gold and can effectively crush and grind gold-bearing ores.
The feeding size can be up to 200-250 mm depending on the model, while the discharging size typically ranges from 0.4 to 0.89 mm.
Industries such as mining, ceramics, smelting, power generation, and chemicals can all benefit from using this small ball mill.
Yes, the ball mill provides two types of feeders: a combined feeder and a cylinder feeder, allowing for versatility based on material requirements.
Typical applications include grinding ores in the mining industry, finishing raw materials in ceramics, and grinding coal for combustion in power generation.
No, maintenance is designed to be straightforward due to the simple structure of the ball mill, making it easier to service and keep operational.
Yes, the small ball mill can be operated in both dry and wet conditions, depending on the specific requirements of the materials being processed.
