SKG-812Z 1325 Cnc Router With Auto Tool Changer For Outdoor Furniture

SKG-812Z CNC Router – High-Performance Woodworking & Cabinet Making Machine

Introduction

The SKG-812Z CNC Router is a versatile and high-performance machine designed for woodworking, cabinet making, and other related applications. Equipped with advanced features such as an automatic tool changer (ATC) spindle, powerful vacuum system, and user-friendly Taiwan Syntec control system, this router enhances efficiency and precision in the manufacturing process. It is ideal for sign making, wood door production, and custom furniture crafting, providing smooth cutting and drilling for various materials.

Key Features

High-Performance ATC Spindle Router:

• Features a powerful 12 kW automatic tool change spindle, capable of 24,000 rpm for fast processing and heavy cutting tasks.
• Ensures a smooth surface on workpieces, even under demanding milling and cutting operations.

Round Type Tool Magazine (12 Tools):

• Holds 12 tools for automatic tool changes, improving efficiency in milling and reducing downtime between operations.

Taiwan Syntec Control System:

• Offers an intuitive and easy-to-use interface for seamless operation and quick response.
• After-sales service is available globally, ensuring reliable support whenever needed.

Imported Linear Guide Rail & Rack:

• Precision ground 30 mm imported linear guide rails and rack ensure smooth and precise travel of the spindle motor assembly.
• The centralized lubrication system guarantees efficient bearing block movement for better performance.

Servo Motor & Driver with Imported Reducer:

• Taiwan Syntec servo motor and driver provide precise and safe machine operation, offering excellent resolution and accuracy during complex tasks.

Automatic Tool Sensor:

• Equipped with a sensor that measures the Z-axis height distance, enhancing tool change accuracy and minimizing errors during operation.

Auto Push Device:

• The auto push device automatically pushes finished boards, improving workflow efficiency.

Auto Loading Device with Suction Cup:

• Automatically picks up boards from the lift table, reducing manual labor and increasing productivity.

Automatic Lift Table:

• Can load boards with a maximum weight of 3000 kg, providing easy material handling for large projects.

Automatic Conveyor Belt:

• Transports finished boards automatically with stop-and-go functionality, streamlining production.

Cabinet Nesting Software:

• Self-developing software system that integrates design, optimization, panel list creation, labeling, quotation generation, CNC file creation, and output processing for more efficient production.

Applications

• Sign Making
• Cabinet Making
• Wood Door Manufacturing
• Wood Furniture Making
• Wood Crafts Making

Specifications

• Model: SKG-812Z
• Spindle Power: 12 kW
• Working Area: 1300×2800 mm
• Drilling Unit: Optional
• Vacuum Area: 7 areas
• Vacuum Power: 7.5 kW
• Max. Moving Speed of X Axis: 80 m/min
• Max. Moving Speed of Y Axis: 80 m/min
• Max. Moving Speed of Z Axis: 20 m/min
• Vacuum Power Air Volume: 250 m³/h
• Total Power: 24.25 kW
• Spindle Quantity: 1
• Machine Size: 9500×3390×2954 mm
• Gross Weight: 3800 kg

Conclusion

The SKG-812Z CNC Router is a highly efficient and precise machine designed for various woodworking and manufacturing applications. With its powerful spindle, user-friendly control system, and automated features, it helps businesses streamline their production processes and enhance productivity. Whether you're in sign making, cabinet making, or wood crafts production, this router offers a complete solution for your needs.

products details

Control system

Taiwan Syntec control system
User-friendly interface, easy operation and fast response.
After-sales service points all over the world

High performance ATC spindle router

Powerful 12KW automatic tool change
Spindle, 24000rpm, Powerful twisting force and fast processing, is suitable for heavy cutting, milling etc., will keep the surface of work pieces very smooth

Round Type Tool Magazine

The round type tool magazine can hold 12 tools, and base on the principle of proximity to change tools. It is more efficient to milling.

Imported linear guide rail and rack

Precision ground 30 mm imported linear guide rails attached to the gantry, with centralized lubrication system to the bearing blocks to guarantee smooth travel of the spindle motor assembly.

Taiwan Syntec servo motor&driver and imported reducer

Professionally made, ensure the machine running accurately in safe with very good resolution and accuracy.

Automatic tool sensor

The sensor will help measure the Z axis height distance

Labeling

Complete the labeling and cutting process through the pass-through more, and the labeling and cutting are uninterrupted.

Auto push device


Auto push device to help push the finished board

Auto loading device suction cup

Auto loading device suction cup pick up the board automatical from lif table
Very efficient to replace workers to go to work, saving labor costs and costs

Automatic lift table


Automatic lift table can load board,maxi loading weight is 3000kg.

Automatic conveyor belt

Automatic conveyor belt for transporting the finished board
Automatic stop and work

Cabinet Nesting Software


1.Self-developing nesting software. Order tracking, packaging systems and other important production links are connected in a software system.
2.Design→Optimize→Create panel list→creat labels→creat quotation of cabinet→Hardware list→creat CNC file（ drilling&cutting→Output
to process

Advertising making

Sign making

Cabinet making

Wood door making

Wood furniture making

Wood crafts making
