Self-propelled Hydraulic Auger Drilling Rig Mini Photovoltaic Solar Pile Driver Machine Crawler

The machine weighs 1200 kg and its dimensions are 2300 mm (L) x 1100 mm (W) x 2300 mm (H).

Standard drilling diameters range from 50 mm to 300 mm. Customized diameters within that range can be supplied on request.

The slide frame has a travel of 2.8 meters, allowing for adjustable drilling depth based on auger length and site requirements.

The rig uses a fully hydraulic system. A single-cylinder diesel engine is available as an optional onboard power source for remote locations.

Yes. The machine is designed for solar projects and is well suited for driving solar piles and related foundation work.

The crawler traveling mode (variable box traveling) and compact footprint provide good stability and mobility on uneven terrain and moderate slopes; site assessment is recommended for steep or highly unstable ground.

The rig accepts a variety of auger types (continuous flight, screw/helical, and other custom bits). Specific tooling for rock or specialty soils can be supplied—please specify soil conditions when ordering.

At 1200 kg and compact dimensions, the unit is easy to load on a small flatbed or trailer. Secure mounting and compliance with local transport regulations are required.

Regular maintenance includes daily checks of hydraulic hoses, fluid levels, filters, bolts and track condition; periodic hydraulic oil and filter changes per manufacturer schedule. Follow the supplier's maintenance manual for exact intervals.

The machine uses a hydraulic radiator for heat dissipation to maintain optimal hydraulic system temperatures during operation.

Yes. Video outgoing inspection and a machinery test report are provided with each unit to verify functionality before shipment.

Standard safety measures include emergency stop controls, protective guards for moving parts, stable crawler undercarriage, and hydraulic overload protection where fitted. Operators should use PPE and follow the provided safety manual.

Yes. Drilling diameter, auger types, power options and other configurations can be customized. Contact the manufacturer with project requirements for a tailored solution.

After-sales support, operator training, and spare parts are typically available through the supplier; availability and lead times vary by region—contact the vendor to confirm details.

Suitability depends on soil type, pile diameter, and required pile depth. Provide site soil reports and desired pile specs to the supplier; they can recommend appropriate auger type, maximum effective depth (based on auger length) and any additional equipment needed.
