Product Description



remote control bulldozer mini dozer bulldozer



SD160 Standard Dryland Bulldozer



Engine: Weichai WD10G178E25



Rated Power: 131KW (178HP) @1850 rpm



Operating Weight: 17 ton



High Quality Remote Control Bulldozer Mini Dozer BulldozerHigh Quality Remote Control Bulldozer Mini Dozer Bulldozer







Advantages:



remote control bulldozer mini dozer bulldozer

Weichai WD10G178E25 engine gives you more power and reliability you need. Improved fuel economy over the previous model with strong torque output and low fuel consumption gives you excellent overall fluid efficiency.

  1. The gearbox uses a planetary gear structure that operates the hydraulic control valve to achieve forward, reverse and various shifts. The structure is planetary gear, muti-plate clutch, hydraulic combined with forced lubrication, which is divided into three forward and three reverse.
  2.  The main frame of the full box structure adopts steel plate welded full box type integral structure, which is welded with the rear axle box. It has high impact load bearing capacity and resistance to bending and twisting. High quality weld seam ensures the main frame has a full life cycle.
  3.  Mainstream 14Mpa working hydraulic system, can greatly reduce the failure rate of hydraulic components with overload protection function.



Product parameter

OverallDimension5140Γ—3388Γ—3180  mm
Operating Weight17000 kg
ENGINEModelWeichai WD10G178E25
TypeWater-cooled, in-line, 4-stroke,direct injection
Number of Cylinders6
Bore Γ— StrokeΞ¦126Γ—130 mm
Piston Displacement9.726 L
Rated Power131 KW (178HP) @1850 rpm
Max Torque765 NΒ·m @1300 rpm
Fuel Consumption214 g/kWΒ·h
            TRANSMISSION SYSTEMTorque Converter3-element, 1 stage, 1 phase
GearboxPlanetary gear type, power-shift, forced lubrication
Central Drive ShaftSpiral bevel gear, single-stage speed reduction, splash lubrication
Steering clutchWet,multi-disc, spring loaded, hydraulically separated, hydraulic control
Steering brakeWet type,floating band structure,foot brake with hydraulic booster
Final drive2-stage speed reduction of spur gear, splash lubrication
                     TRAVEL SPEEDGear1st2nd3rd
Forward0~3.29 km/h0~5.82 km/h0~9.63 km/h
Reverse0~4.28 km/h0~7.59 km/h0~12.53 km/h
UNDERCARRIAGE SYSTEMTypeSprayed beam, suspended structure of equalizer
No. of Carrier Rollers2 each side
No. of Track Rollers6 each side
No. of Track Shoes37 each side
Track Shoe typeSingle Grouser type
Width of Track shoe510 mm
Pitch203.2 mm
Track Gauge1880 mm
Ground Pressure0.067 Mpa
 HYDRAULIC SYSTEMMax Pressure14 Mpa
Pump TypeGear Pump
Displacement243 L/Min
Bore of Working Cylinder110 mm Γ— 2
BLADEBlade TypeStraight-tilt Blade
Blade Capacity4.5 mΒ³
Blade Width3388 mm
Blade Height1150 mm
Max Drop Below Ground540 mm



Work site pictures

High Quality Remote Control Bulldozer Mini Dozer BulldozerHigh Quality Remote Control Bulldozer Mini Dozer BulldozerHigh Quality Remote Control Bulldozer Mini Dozer BulldozerHigh Quality Remote Control Bulldozer Mini Dozer Bulldozer
