Professional Customization Robotic Column Palletizer Automatic Palletizer For Bags

Product Description

Single Column Robot Palletizer

Brief

In the range of robot palletizer made by ZHENGXIA, the single-column robot palletizer represents the simplest and most compact model.
The single-column robot palletizer can handle bags containing stable, aerated or powdery products, permitting partial overlapping of the bags in the layer along both the top and sides, offering flexible format changes. Its extreme simplicity makes it possible to palletize even on pallets sitting directly on the floor.

Work Process

The machine features a sturdy rotating column with a rigid horizontal arm connected to it that can slide vertically along the column. The horizontal arm has a bag pick-up pincer mounted on it that slides along it, rotating around its vertical axis .The machine takes the bags one at a time from the roller conveyor on which they arrive and places them at the point assigned by the program. The horizontal arm descends to the necessary height so that the pincer can pick up the bags from the bag infeed roller conveyor and then it ascends to permit free rotation of the main column.
The pincer traverses along the arm and rotates around its axis to place the bag in the position assigned by the programmed palletizing pattern.
The arm is positioned at the required height and the pincer opens to place the bag on the pallet being formed. At this point, the machine returns to the starting point and is ready for a new cycle.

PRODUCT DETAILS

The special construction solution gives the single-column robot palletizers unique features:
* Possibility of palletizing from several pickup points, in order to handle bags from different lines in one or more palletizing points.
* Possibility of palletizing on pallets set directly on the floor.
* Very compact size

The machine features a PLC-controlled operating system.
Through special programs, the machine can perform virtually any type of palletizing program.
The format and program changes are carried out automatically and very quickly.
The single-column robot palletizer comes complete with safety devices compliant with current international standards.

Bag Kicker

Standing bags are transported to this position, and through the detection of photoelectric switches, it is judged whether the bag has reached the position of pushing the bag. After arriving, the cylinder works and kicks the bag down to a horizontal state and transports it to the Incline Conveyor.

Incline Conveyor

The Incline conveyor is mainly used for the transportation of the product. Inclined conveying makes the material inside the bag flat, ready for the next step of shaping and at the same time play the role of cache packing bags .

Bag Flattener

The bag is shaped and flattened by the square roller vibrating conveyor , so that the palletizing shape is neat and secure,The shaping conveyor can open a certain distance between the products, which is convenient for photoelectric detection and subsequent palletizing.

Roller Conveyor

The bag is conveyed to the Roller Conveyor, the sensors on both sides will detect the bag, stop the conveying and link the palletizer to grab the bag.

Optional Device

MACHINE COMPONENTS

PROJECT SHOW
