Piston Metering Pump 5mpa Pressure Transmission Pump High Efficiency and Small Size

The Piston Metering Pump is a high-efficiency solution for your water distribution and treatment needs. With a compact design and powerful performance, this pump delivers up to 5mpa of pressure, making it ideal for various applications. Its electric power source and durable diaphragm structure ensure reliable operation. Choose the Piston Metering Pump for effective and efficient fluid handling.

Specifications

Attribute	Details
Model Number	JM500L/5
Pressure	5mpa
Voltage	220/380/440V
Power Source	Electric
Power	3KW
Outlet Size	40MM
Type	Reciprocating Diaphragm Pump
Weight	50.000 KG
Certification	CE

Key Features

High efficiency and compact size
Pressure up to 5mpa
Electric power source for reliable operation
Customizable voltage options: 220/380/440V
Durable PTFE diaphragm for anticorrosion
OEM and ODM support available

Applications

Water distribution systems
Water treatment solutions
Chemical processing
Food and beverage industry
Agricultural irrigation
Industrial cleaning applications

Product Info Gallery

Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 11 Dec, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.

1. What is the maximum operating pressure of the Piston Metering Pump JM500L/5?

The JM500L/5 is rated for pressures up to 5 MPa (50 bar), suitable for high-pressure metering and transmission applications.

2. What type of pump is this—piston or diaphragm?

This model is a reciprocating diaphragm metering pump driven by a piston/actuator mechanism. The piston drives a PTFE diaphragm to achieve precise, high-pressure dosing.

3. What are the electrical specifications and power requirements?

Available voltage options are 220 V, 380 V and 440 V. Motor power is 3 kW. Confirm required phase (single- or three-phase) and local connection details with the supplier before installation.

4. What is the outlet/inlet size and physical weight of the unit?

The outlet size is 40 mm. The pump weighs approximately 50.0 kg. For full dimensional drawings, request the product datasheet from the manufacturer.

5. Which fluids and chemicals is this pump compatible with?

The pump uses a PTFE diaphragm for strong chemical resistance and anticorrosion performance. Compatibility depends on all wetted materials—confirm specific chemical compatibility and temperature limits with the manufacturer before use.

6. Is this pump suitable for water distribution and water treatment?

Yes. The pump is designed for water distribution and water treatment applications and is suitable for other industries listed in the product information, such as chemical processing, agriculture, and industrial cleaning.

7. Can this pump be used in food and beverage applications?

It may be used in food and beverage processes if sanitary materials and finishes are specified. Verify that all wetted parts meet applicable food-grade standards and request a sanitary variant if required.

8. How is flow rate and metering accuracy determined?

Flow rate and accuracy depend on stroke length, stroke frequency (or motor speed), and pump head. Ask the manufacturer for performance curves, metering range, and accuracy specifications tailored to your operating conditions.

9. Is the pump self-priming and can it run dry?

Reciprocating diaphragm pumps often have good suction capability, but dry running is not recommended as it can damage the diaphragm and check valves. Use appropriate protections (level sensors, dry-run protection, relief valves) if dry-run risk exists.

10. What routine maintenance is required?

Regular inspections should include checking the diaphragm, check valves, seals, and fasteners. Replace wear parts (diaphragm, valve seats) per the manufacturer's schedule or when signs of wear appear. Keep electrical connections and motor ventilation clean.

11. What spare parts and consumables should I keep on hand?

Common spare parts include PTFE diaphragms, valve assemblies/check balls, seals/gaskets, and motor bearings. Keep a spare diaphragm and valve kit on-hand to minimize downtime.

12. Are OEM and customization options available?

Yes. OEM and ODM support are offered. Customizable options commonly include voltage selection, control panels, stroke adjustment mechanisms, materials for wetted parts, and mounting arrangements.

13. What certifications and safety approvals does the pump have?

This model is CE certified. If you require additional certifications (ATEX, UL, food-grade certifications, etc.), request details from the manufacturer as those may be available on request or via a customized build.

14. What are the installation requirements and recommended accessories?

Install on a stable, level surface and provide proper grounding and motor protection. Recommended accessories include inlet/outlet fittings, pressure relief valve, suction strainer, check valves, flexible connectors to reduce vibration, and a control panel or variable-speed drive if variable flow is needed.

15. How do I purchase this pump and what warranty/support is provided?

Contact the manufacturer or authorized distributor for pricing, lead times, and ordering. Warranty terms and after-sales support can vary—confirm warranty length, spare parts availability, and technical support options with the supplier before purchase.
