Operating Room Ophthalmic Microscope Operating Microscope Coaxial

Are you seeking a state-of-the-art optical solution for precise and efficient examinations? The OLYMPUS® SZX7 microscope system is engineered to enhance your observational capabilities with exceptional clarity and versatility. Imagine a tool that elevates your examination process, providing detailed insights into your samples with ease.

Features

Optics:
Equipped with the renowned OLYMPUS® SZX7 optics for superior imaging quality.

Eyepiece:
Comes with a 10X wide field eyepiece for a broad and clear view.

Observation Angle:
Adjustable observation angle from 0° to 60° for comfortable viewing.

Pupil Distance:
Adjustable pupil distance between 50 mm and 76 mm to accommodate different users.

Diopter Adjustment:
±5D (binocular) adjustment allows for fine-tuning individual vision preferences.

Depth of Field:
Features manual adjustment for depth of field, enhancing focus accuracy.

X-Y Speed Control:
Foot control for 2.2 mm/sec movement, allowing for hands-free adjustments.

Objective Lens:
φ 60 mm apochromatic objective lens for exceptional color accuracy.

Magnification:
Offers a continuous magnification range of 4X to 20X with motorized zoom for flexibility.

Field of View:
Ranges from 8 mm to 50 mm, providing versatility for different applications.

Working Distance:
A generous working distance of ≥180 mm for comfortable operation.

Fine Adjustment:
Foot-controlled fine adjustment of ±20 mm for precise focusing.

Light Source:
Features an aspheric design with a 15V/150W Halogen light, ensuring bright illumination.

Brightness Control:
8-level brightness adjustment controlled by foot switch for optimal lighting.

Intensity:
Delivers illumination intensity of ≥60000 Lux for clear visibility.

Power Control:
Operates on ~220V, 50Hz power supply.

Retinal Protection:
Designed with retinal protection features for user safety.

Red Reflex:
Equipped with a double focus multilayer reflection for enhanced imaging.

Up and Down Adjustment:
Offers ±200 mm adjustment for flexibility in viewing positions.

Base Size:
Stable base dimensions of 720 mm x 720 mm.

Foot Switch Functions:
Controls 11 functions including X-Y focus, motorized focus and zoom, brightness adjustment, and light source switching for seamless operation.

Arm Extension:
Arm can be extended up to 1260 mm for added reach and flexibility.

Conclusion

The OLYMPUS® SZX7 microscope system is an invaluable asset for any laboratory or clinical environment, providing precise measurements and observations with ease. Its advanced features and user-friendly design make it ideal for detailed examinations across various applications. Ready to elevate your observational capabilities? Click below to discover more about the OLYMPUS® SZX7 and see how it can enhance your work!
