Introducing the Oil-free Scroll Compressors, designed for high cleanliness in wafer cleaning and etching processes. These compressors are perfect for industries that require pure air without any oil contamination. With advanced technology and user-friendly features, the...
Select a product option to continue.
Explore funding with Afrimart's partners. Subject to provider approval.
Introducing the Oil-free Scroll Compressors, designed for high cleanliness in wafer cleaning and etching processes. These compressors are perfect for industries that require pure air without any oil contamination. With advanced technology and user-friendly features, they ensure reliable performance while keeping your environment clean and safe.
| Attribute | Details |
|---|---|
| Air Quality | ISO 8573-1 Class 0, 100% Oil-Free |
| Compressor Type | Scroll Oil-Free, Low Vibration, Low Maintenance |
| Control System | Siemens PLC + IoT Remote Monitoring |
| Cooling Method | Air Cooled |
| Drive System | VSD (Variable Speed Drive) for Energy Savings |
| Dryness Level | Pressure Dew Point ≤ -40°C (Optional -70°C) |
| Filtration Accuracy | Multi-stage Filtration Down to 0.01 μm |
| Integration Capability | Supports OPC UA / Modbus + MES Systems |
| Noise Level | ≤ 55 dB - Cleanroom Compliant |
| Pressure Stability | Fluctuation ≤ ±0.1 bar |
| Uptime Reliability | MTBF ≥ 50,000 Hours with Redundancy Options |
| Weight (KG) | 120 |
| Air Capacity | 410 L/min |
| Configuration | Stationary |
| Model Number | MN3.7-8A-SR |
| Power Source | AC Power |
| Warranty | 1 Year |
| MOTOR POWER (KW/HP) | POWER SUPPLY (V/HZ) | AIR DISPLACEMENT (L/MIN) | EXHAUST PRESSURE (MPa) | AIR SUPPLY CONNECTION | EXTERNAL DIMENSIONS L*W*H(MM) | WEIGHT (KG) | NOISE DB(A) |
| 1.5/2 | 380V/50HZ | 140 | 0.8 | RC1/2 | 540*540*770 | 110 | 51±3 |
| 1.5/2 | 380V/50HZ | 140 | 0.8 | RC1/2 | 540*540*1190 | 160 | 51±3 |
| 2.2/3 | 380V/50HZ | 240 | 0.8 | RC1/2 | 540*540*770 | 115 | 53±3 |
| 2.2/3 | 380V/50HZ | 240 | 0.8 | RC1/2 | 540*540*1190 | 165 | 53±3 |
| 3.7/5 | 380V/50HZ | 410 | 0.8 | RC1/2 | 540*540*770 | 120 | 55±3 |
| 3.7/5 | 380V/50HZ | 410 | 0.8 | RC1/2 | 540*540*1190 | 170 | 55±3 |
| 1.5/2 | 380V/50HZ | 120 | 1 | RC1/2 | 540*540*770 | 110 | 51±3 |
| 1.5/2 | 380V/50 HZ | 120 | 1 | RC1/2 | 540*540*1190 | 160 | 52±3 |
| 2.2/3 | 380V/50 HZ | 200 | 1 | RC1/2 | 540*540*770 | 115 | 54±3 |
| 2.2/3 | 380V/50HZ | 200 | 1 | RC1/2 | 540*540*1190 | 165 | 54±3 |
| 3.7/5 | 380V/50HZ | 340 | 1 | RC1/2 | 540*540*770 | 120 | 56±3 |
| 3.7/5 | 380V/50 HZ | 340 | 1 | RC1/2 | 540*540*1190 | 170 | 56±3 |
| Air Quality | ISO 8573-1 Class 0, 100% Oil-Free |
|---|---|
| Compressor Type | Scroll Oil-Free, Low Vibration, Low Maintenance |
| Control System | Siemens PLC + IoT Remote Monitoring |
| Cooling Method | Air Cooled |
| Drive System | VSD (Variable Speed Drive) for Energy Savings |
| Dryness Level | Pressure Dew Point ≤ -40°C (Optional -70°C) |
| Filtration Accuracy | Multi-stage Filtration Down to 0.01 μm |
| Integration Capability | Supports OPC UA / Modbus + MES Systems |
| Noise Level | ≤ 55 dB - Cleanroom Compliant |
| Pressure Stability | Fluctuation ≤ ±0.1 bar |
| Uptime Reliability | MTBF ≥ 50,000 Hours with Redundancy Options |
| Weight (KG) | 120 |
| Air Capacity | 410 L/min |
| Configuration | Stationary |
| Model Number | MN3.7-8A-SR |
| Power Source | AC Power |
| Warranty | 1 Year |
The Oil-free Scroll Compressors meet the ISO 8573-1 Class 0 standard, ensuring 100% oil-free air quality.
These compressors are ideal for wafer cleaning in semiconductor manufacturing, etching processes in electronics production, and any application requiring high cleanliness air, including laboratories and pharmaceutical environments.
The VSD system adjusts the compressor's speed based on the air demand, resulting in lower energy consumption and increased efficiency.
The compressors operate at a noise level of ≤ 55 dB, making them compliant with cleanroom standards and suitable for quiet environments.
The compressors have a mean time between failures (MTBF) of ≥ 50,000 hours, with options for redundancy to ensure continuous operation.
Yes, the compressors feature smart monitoring capabilities with Siemens PLC and IoT integration for remote monitoring.
These compressors offer multi-stage filtration that can filter down to 0.01 μm, ensuring superior cleanliness in air supply.
The Oil-free Scroll Compressors utilize an air-cooled cooling method, which is efficient and suitable for various environments.
The compressors have external dimensions of 2540mm (L) x 540mm (W) x 770mm (H) and weigh approximately 120 kg.
The compressors come with a 1-year warranty, covering manufacturing defects and performance issues.
Yes, the compressors can achieve a pressure dew point of ≤ -40°C, with an optional capability of -70°C for applications requiring extremely dry air.
The compressors are equipped with a Siemens PLC control system, enhancing reliability and ease of use.
The Oil-free Scroll Compressors are designed for low maintenance, reducing operational costs and downtime.
The compressors have an air capacity of 410 L/min, suitable for various industrial applications.
The compressors operate on AC power, with various models available for different voltage and frequency requirements.
