multifunctional drum waste wood crusher hammer mill machine pulverize chipes hammer mill — image 1

multifunctional drum waste wood crusher hammer mill machine pulverize chipes hammer mill
Woodworking Machinery

multifunctional drum waste wood crusher hammer mill machine pulverize chipes hammer mill

  • SKU: 1601162396018
  • Category: Woodworking Machinery

R751,199

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options
Section:
Machinery
SKU:
1601162396018
Payment security and privacy badges

Product Description












sawdust machine It also has a good pulverizing effect on fine soft materials. The size of finished product is from 1mm to 25mm and can be adjusted through the screen. With furniture trim, branches, bark, straw, etc., the output is high, and the material type is more in line with biomass particles, mechanism charcoal, particle board, sawdust board.


The finished products of the three types of equipment are the same, please select the corresponding equipment according to the output and raw materials that are not used. Or call for consultation directly, we will provide you with professional solutions.





We are an Alibaba-certified factory, providing the entire production line of machine-made charcoal and wood pellets, allowing you to purchase at one time, making it more convenient for after-sales and maintenance services.


Negative pressure fan

Negative pressure fan The negative pressure fan extracts the material, which effectively increases the output by 20%, and the negative pressure can also reduce the dust.

Spiral discharge

The bottom screw is directly discharged to ensure high output and effectively reduce dust.


Shakron Duster

Used in conjunction with a sawdust machine, it can collect dust during production. To achieve a pollution-free working environment.

Thickened hammer

High-quality hammers are selected, the weight is similar, and the rotor is calibrated by a dynamic balancing machine, and the speed can reach 2500 rpm.


Model600800100013001500

Feed diameter

(mm)

600*240800*3001000*3501300*3501500*400

Spindle speed

(r/min)

22002200220018001800

Motor

(kw)

22/3337/4555/7590/110132

Diesel engine

(horsepower)

≥30≥50≥75≥180≥220

Yield

(kg/h)

0.6-11.5-22-33-45-7



Frequently Asked Questions

What is the maximum output capacity of the multifunctional drum waste wood crusher?

The maximum output capacity varies depending on the model, with yields ranging from 600 kg/h to 1500 kg/h.

Can the machine handle different types of materials?

Yes, this machine can process various materials such as furniture trim, branches, bark, straw, and more, making it suitable for biomass particles and charcoal production.

What is the size range of the finished product?

The size of the finished product can be adjusted from 1mm to 25mm through the screen.

How does the negative pressure fan work?

The negative pressure fan extracts material, effectively increasing the output by 20% while also reducing dust during operation.

Is it possible to adjust the size of the output material?

Yes, the size of the output material can be adjusted by changing the screen used in the machine.

What type of motor is used in the hammer mill machine?

The machine uses high-efficiency motors with varying power ratings depending on the model, ranging from 22 kW to 132 kW.

Does this machine produce dust during operation?

Yes, however, it is designed to work with a Shakron Duster to collect dust, ensuring a pollution-free working environment.

What safety features are included in the machine?

The machine is equipped with features such as dynamic balancing for the rotor and a sturdy design to ensure safety and reliability during operation.

Can this machine be used for commercial production?

Yes, this multifunctional hammer mill is suitable for commercial production of charcoal and wood pellets.

How does the spiral discharge system benefit the operation?

The spiral discharge system ensures high output and reduces dust by directly discharging materials from the bottom.

Is there customer support available after purchase?

Yes, as an Alibaba-certified factory, we provide comprehensive after-sales and maintenance services for our customers.

What is the spindle speed of the machine?

The spindle speed varies by model, with speeds ranging from 1800 to 2200 rpm.

What should I consider when selecting the right model?

Consider the desired output and the type of raw materials you will be using to select the appropriate model for your needs.

Can this machine be powered by a diesel engine?

Yes, the machine is available with diesel engine options, with horsepower ratings ranging from 30 to 220.

What are the main applications of the finished products?

The finished products are commonly used in biomass energy production, particle boards, and sawdust boards.
