Multifunction Automatic filling and sealing machine for juices palm oil filling and sealing machine
- Section : Machinery
- Category : Industrial Machinery
- SKU : 1600881394249
Multifunction Automatic filling and sealing machine for juices palm oil filling and sealing machine
| Model | Bag Size (Width x Length) | Filling Volume | Capacity | Package Accuracy | Total Power | Dimension (mm) | Weight |
|---|---|---|---|---|---|---|---|
| MR8-200 | 100-200mm x 100-400mm | 5-2500g (depends on product) | 30-60 bags/min (varies by material) | Error ≤ ±1% | 4KW (220V/380V) | 1460×2500×1400 | 1700KG |
| MR8-260R | 120-260mm x 120-350mm | 5-2500g (depends on product) | 25-45 bags/min (zipper bags) | Error ≤ ±1% | 4KW (220V/380V) | 1710x1505x1640 | - |
| MR8-300R | 180-300mm x 180-400mm | Max 5kg | 30-40 bags/min | Error ≤ ±1% | 4KW (220V/380V) | 2460×1830×1460 | - |
| MR8-400R | 280-400mm x 280-650mm | Max 5kg | 20-30 bags/min | Error ≤ ±1% | 4KW (220V/380V) | 2520×1750×1600 | - |
Main Standard Accessories
- Bag feeding system
- PLC control system
- Bag opening device
- Filling system
- Cleaning system
- Hot sealing control system
- Output system
Optional Equipment
- Material metering and filling machine
- Working platform
- Check weigher
- Material elevator
- Finished product conveyor
- Metal detector
Applications
Widely Used in Liquid and Paste Packaging:
- Thin Liquids: Detergent, fruit juice, drinks, soy sauce, rice vinegar, etc.
- Thick Liquids: Tomato sauce, peanut butter, jam, chili sauce, bean paste, etc.
- Other Materials: Liquids or sauces containing particles.
Suitable Pouch Types
- All heat-sealable preformed side seal bags
- Block bottom bags
- Zip-lock bags
- Stand-up pouches (with or without spout)
Features and Characteristics
- Wide Compatibility: Handles all sizes of pre-made pouches.
- Ease of Operation: User-friendly PLC controller and HMI system with fault indications on the touch screen.
- Simplified Adjustment: All processes are integrated into one station for effortless adjustments.
- Speed Control: Frequency-controlled speed adjustments within the operating range.
- Automation: Unmanned weighing and packing process with automatic failure alarms.
Safety and Hygiene
- Safety Alarms: Machine stops and alarms for inadequate air pressure.
- Safety Guards: Equipped with safety switches that stop operations when guards are opened.
- Hygienic Construction: SUS304 stainless steel product-contact parts.
- Maintenance-Free Bearings: Imported engineering plastic bearings eliminate the need for lubrication and contamination.
- Environment-Friendly Vacuum Pump: Oil-free operation ensures a pollution-free workspace.
This MingRui Rotary Packing Machine offers high efficiency, robust safety features, and flexibility for various liquid and paste packaging applications.
- Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 03 Feb, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
- Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
- Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
- Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.
1. What types of liquids can this machine fill and seal?
The machine can handle a wide range of liquids, including thin liquids like fruit juice and soy sauce, as well as thick liquids such as tomato sauce and peanut butter.
2. What pouch types are compatible with this filling and sealing machine?
It is compatible with heat-sealable preformed side seal bags, block bottom bags, zip-lock bags, and stand-up pouches, with or without spouts.
3. What is the maximum filling volume for this machine?
The maximum filling volume varies by model, with options ranging from 5g to 5kg depending on the specific model and product being filled.
4. What is the production capacity of this machine?
The machine can produce between 20 to 60 bags per minute, depending on the model and the material being packaged.
5. What are the dimensions and weight of the machine?
The dimensions and weight vary by model, for example, the MR8-200 model measures 1460×2500×1400 mm and weighs 1700 KG.
6. Does the machine have safety features?
Yes, it includes safety alarms for inadequate air pressure, safety guards that stop operations when opened, and hygienic construction using SUS304 stainless steel.
7. Is the machine easy to operate?
Yes, it features a user-friendly PLC controller and HMI system with fault indications on a touch screen, making operation straightforward.
8. How does the machine ensure accuracy in filling?
The machine maintains a package accuracy error of ≤ ±1%, ensuring precise filling for all products.
9. What kind of maintenance is required for this machine?
The machine is designed with maintenance-free bearings made from imported engineering plastic, eliminating the need for lubrication and reducing contamination.
10. Can the speed of the machine be adjusted?
Yes, the speed can be frequency-controlled within the operating range, allowing for adjustments based on production needs.
11. What are the main standard accessories included with the machine?
Standard accessories include a bag feeding system, PLC control system, bag opening device, filling system, cleaning system, hot sealing control system, and output system.
12. Is there an option for additional equipment?
Yes, optional equipment includes a material metering and filling machine, working platform, check weigher, material elevator, finished product conveyor, and metal detector.
13. What is the total power requirement for the machine?
The machine requires a total power of 4KW and can operate on either 220V or 380V.
14. What materials can be packaged with this machine?
It can package liquids or sauces containing particles, allowing for versatility in product handling.
15. Is the machine environment-friendly?
Yes, it features an oil-free vacuum pump that ensures a pollution-free workspace.
