Lathe Machine gear head lathe engine lathe CD6240B CD6250B CD6260B — image 1

Lathe Machine gear head lathe engine lathe CD6240B CD6250B CD6260B
Lathe

Lathe Machine gear head lathe engine lathe CD6240B CD6250B CD6260B

  • SKU: 60830152888
  • Category: Lathe

Product Description

R225,792

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options
Section:
Machinery
Category:
Lathe
SKU:
60830152888
Payment security and privacy badges

Product Description

Product Description


CDB SERIES LARGE SPINDLE HOLE PRECISION LATHE:

Large spindle bore of 65mm
Main spindle dynamic balanced, and supported at 2 points with taper roller bearings of Harbinbrand
Outward appearance featuring large plains, making the machine more good-looking
Gapped bed ways, which are super-audio frequency hardened
All gears hardened and ground by Reishauer grinding machine
Leadscrew and feed rod interlocked, both with overload protection
Automatic feed stopper
Configuration variable totally according to orders:
Metric or inch system; Right or left hand wheel; Large plane type; Halogen lamp; Quick change tool past; DRO; T-slot compound;
Chuck guard; Leadscrew hood; Rapid traverse motor; Electromagnetic brake; Forced lubrication system.

Product main technical parameters:

MODEL CD6236BCD6240BCD6250BCD6260B
CAPACITIESMax. swing over bed (mm)360400500600
 Max. swing over cross slide185225325360
 Center distance (mm)1000, 1500, 2000mm
 Max swing in gap (mm)490530630730
 Valid length of gap260mm
 Bed width330mm
HEADSTOCKSpindle hole65mm
 Spindle noseISO-C6 or ISO-D6
 Spindle taperMetric 70mm
 Spindle speeds (Number)22-1800rpm (15 steps)
FEEDSMetric threads range (Kinds)0.5-28mm (66kinds)
 Inch Threads range (Kinds)1-56 /inch(66kinds)
 Module threads range (Kinds)0.5-3.5mm (33kinds)
 Diametral threads range (Kinds)8-56 DP(33kinds)
 Longitudinal fees range (Kinds)0.072-4.038mm/rev(0.0027-0.15 inch/rev) (66kinds)
 Cross feeds range (Kinds)0.036-2.019mm/rev(0.0013-0.075 inch/rev) (66kinds)
 Rapid traveling speed of carriage5m/min (16.4ft/min)
 Leadscrew size: Diameter/Pitch35mm/6mm
CARRIAGECross slide travel300mm
 Compound rest travel130mm
 Cross-section size of toolshank20*20mm25*20mm 25*25mm
TAILSTOCKTaper of tailstock sleeveMorse No.5
 Diameter of tailstock sleeve65mm
 Travel of tailstock sleeve120mm
MOTORMain drive motor4.0kw or 5.5kw or 7.5kw  7.5kw
 Coolant pump motor0.125kw
 Rapid traverse motor0.12kw

Details Display








Frequently Asked Questions

What is the maximum swing over bed for the CD6240B lathe?

The maximum swing over bed for the CD6240B lathe is 400mm.

What is the spindle hole diameter for the CD series lathes?

The spindle hole diameter for the CD series lathes is 65mm.

Can the lathe operate in both metric and inch systems?

Yes, the lathe can be configured to operate in either metric or inch systems as per the customer's order.

What kind of bearings support the main spindle?

The main spindle is supported by taper roller bearings of the Harbin brand.

What is the range of spindle speeds for the CD6240B lathe?

The spindle speeds for the CD6240B lathe range from 22 to 1800 RPM across 15 steps.

What type of lubrication system does the lathe use?

The lathe features a forced lubrication system to ensure smooth operation.

What is the valid length of the gap for the CD series lathes?

The valid length of the gap for the CD series lathes is 260mm.

What motor power options are available for the main drive?

The main drive motor options available are 4.0kw, 5.5kw, or 7.5kw.

What is the travel distance of the tailstock sleeve?

The travel distance of the tailstock sleeve is 120mm.

Does the lathe come with an automatic feed stopper?

Yes, the lathe is equipped with an automatic feed stopper for safety and convenience.

What are the cross slide travel and compound rest travel distances?

The cross slide travel is 300mm and the compound rest travel is 130mm.

Is there an option for rapid traverse on the carriage?

Yes, the carriage has a rapid traveling speed of 5m/min (16.4ft/min).

What types of thread ranges can be produced with this lathe?

The lathe can produce metric threads (0.5-28mm), inch threads (1-56/inch), module threads (0.5-3.5mm), and diametral threads (8-56 DP).

Are there customizable features available for this lathe?

Yes, the lathe can be customized with features such as a halogen lamp, quick change tool post, DRO, and more according to orders.

What is the cooling system for the lathe?

The lathe is equipped with a coolant pump motor rated at 0.125kw for efficient cooling during operation.
