Laser Radar Detector Avoidance Scanning Ranging UST-20LX Lidar Sensor
Measuring & Gauging Tools

Laser Radar Detector Avoidance Scanning Ranging UST-20LX Lidar Sensor

  • SKU: 1600547099596
  • Category: Measuring & Gauging Tools

R21,999

Contact Support

SKU:
1600547099596
Payment security and privacy badges

Product Description

Laser Radar Detector Avoidance Scanning Ranging UST-20LX Lidar Sensor



The Laser Radar Detector Avoidance Scanning Ranging UST-20LX Lidar Sensor is an advanced sensor designed to enhance vehicle operating safety. It provides accurate ranging and scanning capabilities, ideal for obstacle avoidance, position sensing, and autopilot applications. This lidar sensor ensures precise detection and supports a range of industrial automation, artificial intelligence, and IoT applications.



Key Features:



  • 20 Meter Ranging Distance: Provides reliable distance measurement up to 20 meters for obstacle detection and position sensing.
  • Laser Radar Technology: Uses advanced laser radar detection for precise and reliable scanning and ranging.
  • 2mW Output: Delivers strong and consistent signal output for stable performance.
  • Position Sensor: Accurately measures and determines the position, essential for autopilot and navigation systems.
  • Wide Application: Suitable for industrial automation, artificial intelligence, and IoT-based systems, enhancing vehicle safety and automation.
  • Durable Construction: Built to withstand harsh conditions, ensuring long-lasting performance in various environments.
  • Easy Integration: Ideal for seamless integration into vehicle safety systems and automated operations.



Parameter
Laser Radar SensorBHX series
Supply voltageDC24V±20%
Measurement resolution5mm
Repeatability±15mm
Laser wavelength905nm
Laser classI (safe to people's eyes)
Data interfaceEthernet 10/100MBd,TCP/IP
Protection ratingIP67
Work Temperature-30ºC to +60ºC
Storage Temperature-40ºC to +85ºC
Light interference50000Lux
Shape90mm×90mm×105mm
Electrical connection
Power wire
Terminal numberColorSignal DefinitionFunction Description
OneBrown24VPower supply positive input
TwoRedNCReserved
ThreeGreyCOMSwitch output COM terminal
FourYellowOUT2Relay output
FiveGreenOUT3Relay output
SixBlue24v-Power supply negative input
SevenWhiteOUT1Relay output
EightBlackNCReserved

Communication wire
Terminal numberColorSignal DefinitionFunction Description
OneOrange whiteTX+EEthernet data transmission
TwoGreen whiteRX+EEthernet data transmission
ThreeOrangeTX-EEthernet data transmission
FourGreenRX-EEthernet data transmission
Model Number
Product NameProduct ModelDetection DistanceScanning
Angle		Angle ResolutionDigital InputOutput


BHX Laser Radar		BHX211A0.3-2m0°-140°0.25°--
BHX221A0-25m0°-180°0.25°-3(Solid state relay)
BHX231B0-10m0°-270°0.5°54(3XRegional output+1XSynchronous output)
BHX241A0-25m10°-130°0.25°-3(Solid state relay)



The Laser Radar Detector Avoidance Scanning Ranging UST-20LX Lidar Sensor is a highly reliable sensor that supports precise obstacle avoidance and position sensing. It is a crucial component for enhancing the safety and functionality of vehicles, especially in automated and autonomous systems.



Product Info Gallery



1818584591235254_phpKproBi1818584591448973_php2IeHGp

Frequently Asked Questions

What is the maximum ranging distance of the UST-20LX Lidar Sensor?

The UST-20LX Lidar Sensor has a maximum ranging distance of 20 meters.

What applications is the UST-20LX Lidar Sensor suitable for?

The UST-20LX is suitable for obstacle avoidance, position sensing, industrial automation, artificial intelligence, and IoT applications.

Is the UST-20LX Lidar Sensor safe for human eyes?

Yes, the UST-20LX operates with a laser class I, which is safe for human eyes.

What type of data interface does the UST-20LX support?

The UST-20LX supports Ethernet 10/100MBd and TCP/IP for data communication.

What is the protection rating of the UST-20LX Lidar Sensor?

The UST-20LX has an IP67 protection rating, making it resistant to dust and water.

What is the operating temperature range for the UST-20LX?

The UST-20LX can operate in temperatures ranging from -30ºC to +60ºC.

How does the UST-20LX handle light interference?

The UST-20LX can operate in light interference conditions up to 50,000 Lux.

What is the resolution of measurements provided by the UST-20LX?

The UST-20LX provides a measurement resolution of 5mm.

Is the UST-20LX easy to integrate into existing systems?

Yes, the UST-20LX is designed for easy integration into vehicle safety systems and automated operations.

What is the storage temperature range for the UST-20LX?

The UST-20LX can be stored in temperatures ranging from -40ºC to +85ºC.

What is the output power of the UST-20LX Lidar Sensor?

The UST-20LX delivers a strong and consistent output power of 2mW.

What materials is the UST-20LX Lidar Sensor constructed from?

The UST-20LX features a durable construction designed to withstand harsh environmental conditions.

What is the shape and dimensions of the UST-20LX?

The UST-20LX has dimensions of 90mm x 90mm x 105mm.

What type of output does the UST-20LX provide?

The UST-20LX provides relay outputs, with multiple signal definitions for various functions.

How does the UST-20LX improve vehicle safety?

The UST-20LX enhances vehicle safety by providing precise obstacle detection and position sensing, essential for autopilot and navigation systems.
