Knelson Type Gold Separator Machine Gold Processing Centrifuge Concentrator - Model KN60

SKU: 1600445034114
Category: Separation Equipment

R442,999

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

View the Full Solution

Section:: Machinery
Category:: Separation Equipment
SKU:: 1600445034114

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

22 Dec, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

The motor drive the concentrate cone rotation in high speed via belt. Feed slurry is then introduced through the stationary feed tube and into the concentrate cone. When the slurry reaches the bottom of the cone it is forced outward and up the cone wall under the influence of centrifugal force. The heavy gold will be stay in layers, and light material will be discharged via outlet. After the machine stop, selected gold sand will be discharged via bottom outlet.

Gold Mining Mineral Separator Machinery Nelson Gold Concentration Centrifuge For Sale

Water jacket centrifuge is also called Nelson centrifuge, which is fit for the selecting and recovery of sand gold and rock gold. It’s an ideal equipment for inland, river sand gold and rock gold selecting to replace amalgamating plate. Now our company have three models. Application shows that the recovery can be as high as 99%, especially for the case in recovering the natural gold in lode ore with 65% of the ore having a milling size of 0. 074mm, the recovery for the natural gold is expected up to 98%. For those natural gold of 0.004mm in particle size, the recovery is 97%. The cleaning up cycle is 1~4 hours for Rock gold, and 4-8 hours for Sand gold. The upgrade ratio is up to 1,000 times.

PRODUCT SPECIFICATIONS

Model	Kn30	Kn60	Kn80
Capacity (t/h)	3-5	15-20	50-70
Feeding size (mm)	0-4	0-6	0-6
Feeding Density (%)	0-50%	0-50%	0-50%
Slurry water Required (t/h)	4-6	10-15	17-25
Concentrate weight (kg)	10	40	60
Motor Power (kw)	2.2	7.5	15
Dimensions (m)	1.21.01.1	1.41.61.6	2.21.71.9
Weight (T)	0.5	1.5	1.8

Frequently Asked Questions

What is the primary function of the Knelson Type Gold Separator Machine?

The primary function of the Knelson Type Gold Separator Machine is to separate and recover gold from sand and rock materials using centrifugal force.

What is the recovery rate of gold using the KN60 model?

The KN60 model can achieve a recovery rate of up to 99% for the natural gold in lode ore, with expected recoveries of 98% for milling sizes of 0.074mm and 97% for particles as small as 0.004mm.

How does the Knelson concentrator work?

The Knelson concentrator works by driving the concentrate cone to rotate at high speed, introducing feed slurry through a stationary feed tube. The centrifugal force then separates heavy gold from lighter materials, allowing the gold to remain in layers while lighter material is discharged.

What are the dimensions of the KN60 model?

The dimensions of the KN60 model are 1.4m x 1.6m x 1.6m.

What is the capacity of the KN60 model?

The KN60 model has a capacity of 5-20 tons per hour.

What is the required slurry water for the KN60 model?

The KN60 model requires approximately 10-15 tons of slurry water per hour.

What is the cleaning up cycle for rock gold and sand gold?

The cleaning up cycle for rock gold is between 1 to 4 hours, while for sand gold, it ranges from 4 to 8 hours.

What is the weight of the KN60 model?

The KN60 model weighs approximately 1.5 tons.

What type of motor power does the KN60 model use?

The KN60 model uses a motor power of 7.5 kW.

Can the Knelson Type Gold Separator be used for both sand gold and rock gold?

Yes, the Knelson Type Gold Separator is suitable for the selection and recovery of both sand gold and rock gold.

What is the upgrade ratio of the KN60 model?

The upgrade ratio of the KN60 model is up to 1,000 times.

Is the Knelson concentrator effective for small particle sizes?

Yes, the Knelson concentrator is particularly effective for small particle sizes, with high recovery rates for particles down to 0.004mm.

What materials can be processed using the Knelson Type Gold Separator?

The Knelson Type Gold Separator can process sand gold and rock gold, making it ideal for mining applications in rivers and inland areas.

What are the other models available besides the KN60?

In addition to the KN60 model, there are also KN30 and KN80 models available, each with different capacities and specifications.

How is the Knelson concentrator different from traditional methods?

The Knelson concentrator uses centrifugal force for separation, which is more efficient and effective than traditional methods like amalgamating plates, particularly for fine gold recovery.
