Products Description
The Jiubang laser screed machine can control the leveling head in real time through the laser receiver, so as to achieve high-precision and rapid concrete leveling, saving time and labor, and is applicable to the construction of workshops, shopping malls, warehouses and other large areas of cement concrete floors.
AUTOMATIC LEVELING DURING CONSTRUCTION
Real-time control and automatic leveling of laser measurement and control system
RAPID CONSTRUCTION AND ONE-TIME FORMING
Flexible operation, high efficiency and small error
Product Paramenters
| Engine model | Brigg & stratton 38E3 | Length | 1260 mm |
| Engine type | Air-cooled, 4-stroke, double-cylinder | ||
| Engine power | 22.8 Kw / 31 HP | Height | 1160 mm |
| Fuel | Gasoline | ||
| Fuel tank | 20 L (Construction duration 8 hours) | Power consumption | 40 - 60 Kw |
| Hydraulic oil tank | 35 L | ||
| Laser control system | Danfoss Laser Control System | Max.cutting diameter | 400 mm |
| Laser transmitter | Swiss Leica transmitter | Chain pitch | 0.404 “ |
| Laser transmitter | Swiss Leica receiver | Chain saw speed | 40 m/s |
| Control effect | Plane, Slope, Double slope (3D) | maxMax. opening of roller | 410 mm |
| Control mode | Microcomputer laser scanning | Max. feed speed | 4 m/s |
| Paving method | Hydraulic mixing cage paving | ||
| Shock plate width | 3000 mm | Max. opening of rear knife | 450 mm |
| Screed thickness | 60 - 300 mm | ||
| Vibration mode | Hydraulic vibration | ||
| Exciting force | 2000 N | ||
| Drive mode | Reducer motor integrated | ||
| Walking speed | 0 - 4 Km/h (Speed adjustable) | ||
| Tyre | Solid anti-skid and stab-resistant tire (Optional wide tire) | ||
| Dimensions | 3300 x 3460 x 1650 mm | ||
| Weight | 1000 Kg |
Details Images
01
CONTROL SYSTEM
Monitor the working status in real time to ensure that the overall elevation of the ground is consistent
02
LASER SYSTEM
Laser automatic leveling, automatic elevation
03
VIBRATING PLATE
Alloy material, widened and thickened, more stable work
04
HIGH-FREQUENCY VIBRATOR
High frequency, large amplitude, smooth appearance after construction
05
STIRRER
Make concrete mixing more uniform
06
TYRE
Solid anti-skid and stab-resistant tires, optional wide tires
MORE DETAILS
More real details photos
PRODUCT PHOTOGRAPH
More real product photos
Specification details are not available in this product description. Contact our team for more information.
The primary function of this machine is to achieve high-precision and rapid concrete leveling for road construction and large areas such as workshops, shopping malls, and warehouses.
The laser screed uses a laser receiver to control the leveling head in real time, ensuring automatic leveling and precise elevation during the concrete pouring process.
The dimensions of the Hydraulic Four Wheels Concrete Leveling Machine are 3300 mm in length, 3460 mm in width, and 1650 mm in height.
This machine operates on gasoline and has a fuel tank capacity of 20 liters, allowing for approximately 8 hours of continuous operation.
The machine has a maximum cutting diameter of 400 mm.
The machine weighs approximately 1000 kg.
The machine uses a hydraulic mixing cage paving method to ensure efficient concrete placement.
Yes, the walking speed of the machine can be adjusted between 0 to 4 km/h.
The machine is powered by a Brigg & Stratton 38E3 engine with a power output of 22.8 kW, or 31 HP.
The machine features solid anti-skid and stab-resistant tires, with an option for wider tires available.
The machine utilizes hydraulic vibration for effective concrete leveling.
The machine is equipped with the Danfoss Laser Control System for real-time monitoring and control of the leveling process.
The machine can accommodate a screed thickness ranging from 60 mm to 300 mm.
Yes, the machine features an automatic leveling system that adjusts based on laser measurements during operation.
The high-frequency vibrator provides a large amplitude, ensuring a smooth surface appearance after concrete construction.
