Product Description

Horizontal Packing Machine

Machine functions and features：

1. The feeding conveyor is made of stainless steel and can be used to contact food;

• we can make different conveyors according to different products;

• Uniform and stable transmission speed to prevent product from moving.

• Very easy to disassemble conveyor for easy replacement to suit different products.

2. Bag former's width and bag sealer's height is adjustable for different products' dimension;

• Bag sealer can be coated with teflon for sealing PE plastic material;

• The PID controller can control the temperature very precisely to suit different types of packaging materials.

3. Easy control of machine operation via touch screen, such as adjustment of bag size, running speed, seal temperature, coding machine, color mark detecting etc; Japanese imported electrical configuration ensures stable operation of the machine; All transmission parts are quenched to extend machine life and stability.

Specifications:

Brand	KINGHANLONG
Model	KL-250XZ
Measuring	manual measurement
Film width Max	250mm
Bag width	30-110mm
Bag length	90-220mm
Bag height Max.	70mm
Power	220V, 50/60HZ, 2.4KW
Speed	40-90 packs/min
Weight	440KG
Pull bag way	Step motor pull bag

No.	Items	Brand	Place of origin
1	Touch Screen	SHANGHAI FLEXEM	China
2	Converter	PANSONIC	Japan
3	PLC	PANSONIC	Japan
4	Proximity Switch	LEIKE	German
5	Electric Eye	SHANGHAI YATAI	China
6	Solid State Relay	HEIGHT TECH	German
7	Button	SCHNEIDER	German
8	Power Supply	MEAN WELL	China
9	Temperature Control	SHANGHAI YATAI	China
10	Contact Component	WEIDMULLER	German
11	Grounding Type Terminal Block	WEIDMULLER	German
12	Base Terminal Block	WEIDMULLER	German
13	Interrupter	TENGEN	China
14	Heat Pipe	ZHONGXING	China
15	Brush Assembly	MODA	China

Product Info Gallery

Frequently Asked Questions

What is the maximum bag width that the Horizontal Packing Machine can accommodate?

The Horizontal Packing Machine can accommodate a maximum bag width of 110mm.

Is the feeding conveyor made from food-grade materials?

Yes, the feeding conveyor is made of stainless steel, making it suitable for direct contact with food.

How do I adjust the bag size on the machine?

You can easily adjust the bag size through the touch screen interface, which allows you to modify settings such as bag width and bag length.

What is the speed range of the packing machine?

The packing machine operates at a speed range of 40 to 90 packs per minute.

Can the machine handle different types of packaging materials?

Yes, the machine is equipped with a PID controller that allows precise temperature control, making it compatible with various packaging materials.

What is the power requirement for the Horizontal Packing Machine?

The machine requires a power supply of 220V, 50/60Hz, with a power consumption of 2.4KW.

How heavy is the Horizontal Packing Machine?

The machine weighs approximately 440KG.

What type of electrical components are used in the machine?

The machine uses high-quality imported electrical components, such as Panasonic PLC and converters, ensuring stable operation.

Is it easy to replace the conveyor for different products?

Yes, the conveyor is designed for easy disassembly, allowing for quick replacements to suit different products.

What is the range of bag lengths the machine can produce?

The Horizontal Packing Machine can produce bags with lengths ranging from 90mm to 220mm.

Can the bag sealer be adjusted for different bag heights?

Yes, the bag sealer's height is adjustable to accommodate different product dimensions.

What features enhance the durability of the machine?

All transmission parts are quenched to extend machine life and stability, ensuring durable performance.

How do I access the coding machine and color mark detection features?

These features can be easily controlled through the touch screen interface of the machine.

Is this machine suitable for both small and large production runs?

Yes, the Horizontal Packing Machine is designed to be efficient for both small and large production runs, thanks to its adjustable settings.

Where is the Horizontal Packing Machine manufactured?

The Horizontal Packing Machine is manufactured by KINGHANLONG, with various components sourced from reputable manufacturers in China, Japan, Germany, and more.
