High-output Wood Multiple Heads Sawmill Timber Multi-blade Saw Machine

Multiple Head Horizontal Band Sawmill – High-Performance Wood Cutting Machine

Introduction

The Multiple Head Horizontal Band Sawmill is a versatile and powerful wood cutting machine designed for industrial use. It features multiple saw blades, offering efficient and precise wood sawing. Available in various configurations, it is capable of processing logs into planks of various sizes and thicknesses. This machine is ideal for sawmills, lumber production, and large-scale wood processing.

Key Features

Multiple Blade Configuration:

• Available with 2 to 6 saw blades for greater flexibility in wood cutting operations. Each blade ensures precise and smooth cutting.

Variable Frequency Speed Adjustable Conveyor:

• The feeding mode is equipped with a variable frequency adjustable conveyor, allowing for customized speed control and enhancing cutting efficiency.

Computer Touch Screen Numerical Control:

• The sawmill is controlled through a computer touch screen, offering numerical control settings for precise adjustments and easy operation.

Wide Cutting Range:

• Capable of sawing wood widths between 50-300 mm and thicknesses between 2-260 mm, providing versatility for various types of wood processing.

Durable Band Saw Blades:

• Uses band saw blades with widths ranging from 41-75 mm and a length of 4400 mm, providing robust cutting power for different wood types.

Heavy-Duty Construction:

• The sawmill is built with a strong frame to handle demanding cutting tasks. It features saw wheel diameters of 700 mm, ensuring stability and precision during operation.

Powerful Motors:

• Equipped with multiple 15 kW motors, depending on the model, delivering high cutting power for various wood sizes and processing speeds.

Specifications

• Models: DT300-2, DT300-3, DT300-4, DT300-5, DT300-6
• Sawing Wood Width: 50-300 mm
• Sawing Thickness: 2-260 mm
• Band Saw Blade Width: 41-75 mm
• Band Saw Blade Length: 4400 mm
• Saw Wheel Diameter: 700 mm
• Main Motor Power: 15 kW (x2 to x6 sets, depending on model)
• Feeding Mode: Variable frequency speed adjustable conveyor
• Sawn Controlling: Computer touch screen numerical control setting
• Machine Length: 4500 mm to 11500 mm (depending on model)
• Total Weight: 1500 kg to 5000 kg (depending on model)

Conclusion

The Multiple Head Horizontal Band Sawmill is a high-efficiency wood cutting machine, perfect for large-scale sawmill operations. With its multiple blade configurations, advanced control system, and powerful motor setup, it offers exceptional precision and performance for industrial wood processing needs.
