Product Description

High Speed Simple Model Paper Cup Machine with Counting System (Model: MYC-OCM12)

Specifications:

Paper Cup Size: 1.5 ~ 16 OZ (Mould exchangeable, Max Cup Height: 136mm, Max Bottom Width: 80mm)

Rated Speed: 80-100 pcs/min (Speed affected by cup size, paper quality & thickness ,one set mould for one cup size speed)

Raw Material: One or Two side PE coated Paper (Popular for Hot and Cold drink cups)

Suitable Paper Weight: 140-350 gsm

Power Source: 50/60HZ, 380V/220V (better use 380V, 3 Phase) or special power requirement.

Total Power: 5 KW

Total Weight: GW/NW: 2000 KG / 1900 KG

Working Air Source:

Air Pressure: 0.4 Mpa

Air Out-put: 0.6 m³/minute

Need to buy Air Compressor (by user)

Cup Side Welding: Ultrasonic heater

Cup Bottom Heating:

1 side PE paper by heater knurling;

2 side PE paper by cool device (circle water) knurling.

Cup Bottom Knurling: Heater knurling (if used single PE coated paper)

Product info Gallery:

redirectFileUrl.htm?appkey=OneChat&id=3277154866&parentId=1698336324&secOperateAliId=MC1IDX1zlyK4i5W8xgZV-3-M3W2KM7WVN5O5RNo7gmru985BdTZFjwa-N-eOrFc1CDfHPr8&fileAction=imagePreview&scene=1&format=quality,q_100

Frequently Asked Questions

What is the maximum cup size that the High Speed Simple Model Paper Cup Machine can produce?

The machine can produce cups with a maximum height of 136mm and a maximum bottom width of 80mm, suitable for sizes ranging from 1.5 to 16 ounces.

What is the rated speed of the machine?

The rated speed of the machine is between 80 to 100 cups per minute, depending on the cup size, paper quality, and thickness.

What types of paper can be used with this machine?

The machine is suitable for one or two side PE coated paper, which is popular for both hot and cold drink cups.

What is the suitable paper weight for the machine?

The machine can handle paper weights ranging from 140 to 350 gsm.

What are the power requirements for the machine?

The machine operates on a power source of 50/60HZ and can use either 380V or 220V. It is recommended to use 380V, 3 Phase for optimal performance.

What is the total power consumption of the machine?

The total power consumption of the High Speed Simple Model Paper Cup Machine is 5 KW.

What is the weight of the machine?

The total weight of the machine is 2000 KG, with a net weight of 1900 KG.

What air source is required for the machine to operate?

The machine requires an air pressure of 0.4 Mpa with an air output of 0.6 m³/minute. Users need to purchase an air compressor separately.

How does the cup side welding process work?

The cup side welding is done using an ultrasonic heater, ensuring strong and reliable seals.

How is the cup bottom heating managed?

For one side PE paper, the cup bottom is heated using a heater knurling method. For two side PE paper, a cool device with circulating water is used for knurling.

What is the knurling process for the cup bottom?

The cup bottom knurling is achieved using heater knurling if only single PE coated paper is used.

Is the machine suitable for both hot and cold beverage cups?

Yes, the machine is designed to produce cups suitable for both hot and cold beverages due to its compatibility with PE coated paper.

Can the machine produce different cup sizes using the same mould?

No, the machine requires a specific mould for each cup size, and speed may vary based on the cup size chosen.

What maintenance is required for the machine?

Regular maintenance includes checking the ultrasonic heater, ensuring proper air pressure, and inspecting the heating elements for optimal performance.
