High Differential Pressure Pump, Turbine Pump, Lpg Filling Pump

0 Customer Reviews

Add To Wishlist Share to Social

Section : Electrical & Tools
Category : Pumps & Parts
SKU : 60719851638

High Differential Pressure Pump, Turbine Pump, LPG Filling Pump

The High Differential Pressure Pump, Turbine Pump, LPG Filling Pump is a powerful and reliable solution for your LPG filling needs. Designed for high pressure and efficiency, this pump is perfect for transporting LPG gas and other compatible chemicals. Its robust construction and advanced features make it an essential tool for various industrial applications.

Specifications

Attribute	Details
Application	District Energy
Pressure	High Pressure
Voltage	220V/380V
Customized Support	OEM
Power Source	Electric
Structure	Single-stage Pump
Brand Name	Macbeyond
Model Number	Pump with Coupling Drive
Horsepower	5.5 kW
Outlet Size	1"
Liquid	LPG
Chemical Compatibility	LPG gas
Discharge Pipe Size	1 in
Speed	60Hz 3450 RPM or 50Hz 2880 RPM
Max. Working Pressure	27.6 bar (400 PSI)
Max. Differential Pressure	17.2 bar (250 PSI)
Max./Min. Temperature	-32℃~107℃
Power of Motor	5.5 kW
Usage	LPG
Selling Units	Single item
Single Package Size	95X45X60 cm
Single Gross Weight	153.000 KG

Key Features

High differential pressure capability
Designed for LPG and compatible chemicals
Single-stage structure for efficient operation
Customizable options available
Robust electric motor with 5.5 kW power

Applications

LPG filling stations
District energy systems
Industrial gas transportation
Chemical processing plants
Fuel supply systems

Product Info Gallery

Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 11 Dec, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.

1. What is the High Differential Pressure Pump used for?

This pump is designed primarily for LPG filling and transportation, and is also suitable for district energy systems, industrial gas transfer, chemical processing plants and other applications where high differential pressure for LPG or compatible chemicals is required.

2. What are the key performance limits (pressure and temperature)?

Maximum working pressure is 27.6 bar (400 PSI). Maximum differential pressure (pressure rise the pump can produce) is 17.2 bar (250 PSI). Rated operating temperature range is -32°C to 107°C.

3. What is the motor power, speed and voltage for this pump?

Standard motor power is 5.5 kW. Typical speeds are 3450 RPM at 60 Hz and 2880 RPM at 50 Hz. Voltage options are listed as 220V/380V — please confirm required supply (single-/three-phase and local voltage) when ordering.

4. What is the inlet/outlet size and pump structure?

The pump uses a 1" outlet (discharge pipe size 1") and is a single-stage turbine pump with a coupling drive.

5. What fluids is this pump compatible with?

It is specified for LPG and LPG-compatible chemicals. For other chemicals or mixtures, please provide the fluid specifications to the manufacturer to confirm material and seal compatibility.

6. Does the pump come with explosion-proof or hazardous-area certified motors?

The standard listing does not specify hazardous-area certification. Explosion-proof (ATEX/IECEx) or other hazardous-area motor options may be available as customizations—please request certified options when you place your order.

7. What information do I need to provide to get the correct pump configuration?

Provide required flow rate (l/min or m3/h), suction and discharge pressures, fluid properties (composition, vapor pressure, temperature), supply voltage/frequency, piping sizes, and any required certifications or materials. The manufacturer can then supply the correct pump curve and configuration.

8. How do I get pump performance (flow) data?

Flow and head are determined from the pump performance curve for the selected configuration. Contact the supplier or manufacturer with your operating conditions to receive the correct pump curve and expected flow at your duty point.

9. What are the physical package dimensions and shipping weight?

Single package size is 95 x 45 x 60 cm and the single gross weight is listed as 153 kg.

10. What maintenance is recommended for LPG service?

Regular visual inspections for leaks, periodic checks of mechanical seals and couplings, monitoring motor bearings and lubrication per motor manufacturer instructions, verifying suction conditions to avoid vaporization, and replacing wear parts (impellers, seals) according to operating hours and condition. Follow detailed maintenance intervals provided by the supplier.

11. Are spare parts and service available?

Yes. Spare parts and service support are available through the manufacturer/supplier. Provide pump model and serial number when requesting parts or service to ensure correct items are supplied.

12. Can this pump be customized or ordered as OEM?

Yes. OEM/customization support is offered. Options may include different materials, certified motors, instrumentation, flange/coupling arrangements and other modifications—discuss requirements with the supplier.

13. What safety measures should I follow when operating the pump with LPG?

Use equipment rated for flammable service in hazardous areas, ensure proper grounding and bonding, install leak detection and ventilation, follow purge and start/stop procedures for LPG systems, and ensure operators are trained. Always follow local codes and standards for LPG handling.

14. How do I place an order and what information should I include?

Contact the supplier or authorized dealer with the product model (Macbeyond, 'Pump with Coupling Drive'), required electrical supply (voltage/frequency/phase), operating duty point (flow, suction/discharge pressure, temperature), any certification or material requirements, and shipping/billing details. The product is sold as a single item unit.
