Heavy Duty Automatic Tools ATC CNC Milling Machine for Metal Processing

The Heavy Duty Automatic Tools (ATC) CNC Milling Machine is a professional and robust machine designed for efficient metal processing. Ideal for industries that require high-precision engraving, cutting, and milling, this machine supports a variety of materials such as copper, aluminum, stainless steel, and more.

Key Features & Specifications:

Cast Iron Frame:

The cast iron frame undergoes vibration aging treatment for enhanced stability and reduced deformation during operation.

Ball Screw Drive:

X, Y, and Z axes are driven by imported ball screws, ensuring high precision, smooth movement, and long service life.

Linear Circular Guide:

Equipped with Taiwan HIWIN linear square guides (20mm diameter) for superior durability and extended life.

Cooling System:

A stainless steel sink cooling system for effective cooling of tools and materials during metal, stone, or glass processing.

Control System:

Features the DSP NK105 control system for enhanced ease of use and accuracy.

Water Cooling Spindle:

5.5 KW water-cooling spindle with variable speed (0-18,000 rpm) for efficient metal processing.

3D Multi-Layer Processing:

Supports multi-layer 3D processing for smooth, high-speed engraving and cutting.

Emergency Stop Button:

Ensures safe operation with an emergency stop feature for quick shutdown.

Software Compatibility:

Compatible with a range of CAD/CAM software like Type3, Artcam, Castmate, Ucanam, etc.

Worktable:

The aluminum T-slot worktable offers higher precision and is more stable than the mobile gantry type.

Machine Specifications:

No.	Description	Parameter
1	Model No.	TPR-0609 Metal Mold CNC Milling Machine
2	X, Y, Z Area	600x900x200mm (200mm feeding height)
3	Table Surface	T-slot table
4	Frame	Cast steel structure with steel tube stands frame
5	X, Y, Z Structure	Ballscrews
6	Spindle	5.5 KW, water cooling, 0-18,000 rpm
7	Inverter	5.5 KW
8	Driving System	Leadshine brand hybrid servo
9	Max. Moving Speed	6m/min
10	Max. Working Speed	3.5m/min
11	Control System	DSP NK105
12	Command Language	G code
13	Working Voltage	AC 220V/380V
14	Software Compatibility	Various CAM software
15	Tool Cooling System	Yes
16	Lubrication System	Yes
17	Running Environment Temperature	0-60°C
18	Relative Humidity	30% - 75%
19	Packing Size	1400x1400x2000mm
20	Net Weight	600kg
21	Gross Weight	650kg
22	Optional Parts/Function	Rotary attachment, multi-head processing

Applications:

Industries: Widely used in engraving and cutting work for advertising signs, badges, logos, molds, and industrial equipment.
Materials: Ideal for processing metals (copper, aluminum, iron, stainless steel, alloys) and non-metals like acrylic, wood, MDF, stone, jade, etc.

Advantages:

High Precision: Equipped with advanced ball screw and linear guide systems for accurate machining.
Versatile: Suitable for both metal and non-metal materials.
Efficient Processing: Handles multiple layers and complex 3D engravings with high speed.
Safety Features: Includes an emergency stop button to enhance safety during operation.

Heavy Duty Automatic Tools ATC Machine Mould Milling Machine Change Metal 6090 Professional Cnc Metal for Copper Aluminum

No.	Description	Parameter
1	Model No.	TPR-0609 metal mold cnc milling machine
2	X,Y,Z Area	600x900x200mm (200mm is feeding height, Z working area is 180mm).
3	Table Surface	T-slot table
4	Frame	Cast steel structure, steel tube stands frame
5	X,Y,Z structure	Ballscrews
6	Spindle	5.5 KW,water cooling, 0-18000rpm, professional metal processing spindle
7	Inverter	5.5 KW
8	Driving system	Leadshine brand hybride servo
9	Max.moving speed	6m/min
10	Max. Working Speed	3.5/min
11	Control system	DSP NK105
12	Command language	G code
13	Working Voltage	AC220V/380V
14	Software Compatibility	Various CAM softwares
15	Tool cooling system	Yes
16	Lubricate system	Yes
17	Running Environment Temperature	0-60 Centigrade
18	Relative Humidity	30% - 75%
19	Packing Size	1400x1400x2000mm
20	N.W.	600kg
21	G.W.	650KG
22	Optional parts/function	Rotary attachemnt for columns carving 2/3/4 heads, can process 2/3/4 products at a time

Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 14 Dec, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.

1. What materials can the Heavy Duty ATC CNC Milling Machine process?

The machine is designed to efficiently process a variety of materials including metals like copper, aluminum, iron, stainless steel, as well as non-metals such as acrylic, wood, MDF, stone, and jade.

2. What is the maximum working area of the machine?

The maximum working area of the Heavy Duty ATC CNC Milling Machine is 600x900x200mm, with a feeding height of 200mm and a Z working area of 180mm.

3. What type of control system does this machine use?

The machine features the DSP NK105 control system, which enhances ease of use and accuracy during operation.

4. Is the machine compatible with CAM software?

Yes, the Heavy Duty ATC CNC Milling Machine is compatible with various CAD/CAM software such as Type3, Artcam, Castmate, Ucanam, and more.

5. What is the spindle power and speed of the machine?

The machine is equipped with a 5.5 KW water-cooled spindle that has a variable speed range of 0 to 18,000 rpm for efficient metal processing.

6. How does the cooling system work?

The machine includes a stainless steel sink cooling system that effectively cools tools and materials during processing to prevent overheating.

7. What safety features does the machine have?

The machine is equipped with an emergency stop button that ensures safe operation and allows for quick shutdown in case of emergencies.

8. What is the weight of the Heavy Duty ATC CNC Milling Machine?

The net weight of the machine is 600 kg, while the gross weight is 650 kg.

9. What are the advantages of using this machine?

The Heavy Duty ATC CNC Milling Machine offers high precision due to its advanced ball screw and linear guide systems, versatility for processing both metal and non-metal materials, and efficient handling of complex 3D engravings.

10. Can the machine be used for 3D processing?

Yes, this machine supports multi-layer 3D processing, allowing for smooth and high-speed engraving and cutting.

11. What is the maximum moving speed of the machine?

The maximum moving speed of the Heavy Duty ATC CNC Milling Machine is 6 m/min, while the maximum working speed is 3.5 m/min.

12. What type of frame does the machine have?

The machine features a cast iron frame that has undergone vibration aging treatment, providing enhanced stability and reduced deformation during operation.

13. What optional parts or functions are available for this machine?

Optional parts include a rotary attachment for column carving and multi-head processing capabilities, allowing for the processing of multiple products simultaneously.
