The HC-CS202 Ultrasonic Concrete Crack Depth Testing Machine is a cutting-edge device designed to deliver accurate and reliable measurements of surface crack depths in concrete structures. Its advanced ultrasonic technology and user-friendly interface make it a vital tool for construction and structural integrity assessments.
| Function | parameter |
| number of channels | dual channel |
| Display mode | 5-inch color LCD screen (720x1280) |
| Storage capacity | 16G |
| Sampling interval | 0.025μs ~ 2000μs multi-level optional |
| Sampling length | 512 points ~ 2048 points multi-level optional |
| Emission pulse | width 0.1μs ~ 100μs |
| Emission voltage | 125V, 250V, 500V, 1000V multi-level optional |
| Trigger circuit | internal trigger mode |
| Transfer method | dedicated U disk |
| Charging power supply | AC100~240 V, 50/60Hz, output 12.6V DC, 3.0A |
| Host volume | 200×144×65(mm) |
| Host weight | 1.35kg |
| Working temperature | -20 ~ +60℃ |
| Depth measurement range | 5 to 500 mm |
The HC-CS202 Ultrasonic Concrete Crack Depth Testing Machine is a powerful and versatile tool for construction and inspection professionals. Its advanced technology and customizable features make it a trusted choice for assessing structural safety and durability.
| Function | parameter |
|---|---|
| number of channels | dual channel |
| Display mode | 5-inch color LCD screen (720x1280) |
| Storage capacity | 16G |
| Sampling interval | 0.025μs ~ 2000μs multi-level optional |
| Sampling length | 512 points ~ 2048 points multi-level optional |
| Emission pulse | width 0.1μs ~ 100μs |
| Emission voltage | 125V, 250V, 500V, 1000V multi-level optional |
| Trigger circuit | internal trigger mode |
| Transfer method | dedicated U disk |
| Charging power supply | AC100~240 V, 50/60Hz, output 12.6V DC, 3.0A |
| Host volume | 200×144×65(mm) |
| Host weight | 1.35kg |
| Working temperature | -20 ~ +60℃ |
| Depth measurement range | 5 to 500 mm |
| Precise Ultrasonic Detection | Utilizes ultrasonic technology to measure concrete surface crack depths with high accuracy. |
| Color LCD Screen | Features a vibrant and clear color LCD screen for easy data visualization and operation. |
| Lightweight and Portable | Weighing just 7.5 kg, it is compact and easy to transport for on-site testing. |
| Versatile Applications | Suitable for a wide range of uses, including construction site evaluations, structural inspections, and quality control. |
| Customizable Support | Offers OEM, ODM, OBM, and software reengineering options to meet specific project requirements. |
| Durable Design | Built to withstand challenging environments, ensuring reliable performance over time. |
| User-Friendly Interface | Simplifies operation, making it accessible for professionals across industries. |
The HC-CS202 can measure crack depths ranging from 5 to 500 mm.
The HC-CS202 utilizes advanced ultrasonic technology to accurately measure the depth of surface cracks in concrete by sending ultrasonic waves and analyzing their reflections.
Yes, the HC-CS202 is lightweight at just 7.5 kg and designed for easy transport, making it suitable for on-site testing.
The HC-CS202 features a vibrant 5-inch color LCD screen with a resolution of 720x1280, allowing for easy data visualization.
Yes, the HC-CS202 offers customizable support, including OEM, ODM, OBM, and software reengineering options to meet specific project requirements.
The HC-CS202 has a storage capacity of 16G, allowing for ample data storage during testing.
The HC-CS202 operates effectively within a temperature range of -20 to +60 degrees Celsius.
The HC-CS202 supports dual channel measurements for enhanced functionality.
The HC-CS202 offers multiple emission voltage options including 125V, 250V, 500V, and 1000V.
The HC-CS202 is designed for accurate and reliable measurements of surface crack depths in concrete structures, essential for construction site evaluations and structural inspections.
The HC-CS202 features a user-friendly interface that simplifies operation, making it accessible for professionals across various industries.
The host unit of the HC-CS202 weighs 1.35 kg, making it lightweight and easy to handle.
The HC-CS202 offers a sampling interval range from 0.025μs to 2000μs, with multi-level options available.
Yes, the HC-CS202 is built to withstand challenging environments, ensuring reliable performance over time.
The HC-CS202 requires an AC power supply of 100-240 V at 50/60Hz, with an output of 12.6V DC and 3.0A.
