Filling Machines

Food Level 25ml Gel Yogurt Syrup Liquid Filling Machine

SKU: 1601151474626-1720855788
Category: Filling Machines

R240,000

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Filling Machines
SKU:: 1601151474626-1720855788

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

18 Dec, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

"Rotary pump liquid filling" is the precise process of transferring liquids into containers using rotary pumps. This method is widely employed in industries like pharmaceuticals, food, and chemicals due to its accuracy and consistency. Rotary pumps, with their rotating mechanisms, create a low-pressure zone that draws in the liquid, ensuring precise and efficient filling. These pumps can handle a variety of viscosities and are essential for automating filling processes, maintaining product quality, and reducing waste.

Filling servo power	1kw
Conveying servo power	0.75kw
Feeding pump power	0.55kw(optional)
Power supply voltage single-phase	220v50hz
Hopper volume	37L
Maximum bottle width	150mm
Maximum bottle height	300mm
Applicable filling volume	50-5000ml

1.Type change

Can change the automatic type and semi-automatic type flexible at the same machine. Automatic Type: without bottle stoppers and easy to adjust.

Semi-automatic Type: with scale

2. Rotor pump

Rotor pump is full paint surface and full stainless steel pump.

3. The entire leveling structure is customized and improved to compensate for processing errors and achieve uniform clearance between the rotor and the cavity.

Nowadays, small gaskets like this are generally used for flattening. Once disassembled, it is difficult for customers to put them back into their original positions. Once the error exceeds the tolerance, the rotor will be directly stuck. The following is the
situation where the rotor is eccentrically stuck.

- Rotor wear and cavity wear will cause the entire rotor pump to be scrapped.

4. Sealed structure

We use mechanical friction seals, which are easy to remove and replace.

5. The pump cover structure has been improved.

If it is repaired on site, all routine maintenance such as rotor replacement and sealing ring replacement can be accomplished by
removing the pump cover without removing the entire pump body. This is very convenient for customers.

This is the structure of most pump bodies currently. The screws in the pump chamber are at the bottom, and the entire pump body
needs to be removed to remove it. The shaft seal is between the white reducer and the stainless steel pump chamber.

6. Fuma Wheel

It’s more convenient when it’s places or moved.

7. Stop-and-go conveyor belt

Guaranteed liquid filling speed.

Frequently Asked Questions

What is the filling capacity range of the Food Level 25ml Gel Yogurt Syrup Liquid Filling Machine?

The machine can fill volumes ranging from 50ml to 5000ml, making it suitable for a variety of container sizes.

Can this machine be used for both automatic and semi-automatic filling?

Yes, the Food Level 25ml Gel Yogurt Syrup Liquid Filling Machine can switch between automatic and semi-automatic types, providing flexibility for different operational needs.

What type of materials is the rotor pump made of?

The rotor pump is constructed with a full paint surface and is made of full stainless steel, ensuring durability and resistance to corrosion.

What is the hopper volume of the machine?

The hopper volume of the Food Level 25ml Gel Yogurt Syrup Liquid Filling Machine is 37 liters.

What is the maximum bottle width and height that this machine can accommodate?

The maximum bottle width that can be accommodated is 150mm, and the maximum bottle height is 300mm.

How does the rotary pump ensure accurate filling?

The rotary pump creates a low-pressure zone that draws in the liquid, allowing for precise and efficient filling, making it ideal for maintaining product quality.

What are the power requirements for this machine?

The machine requires a single-phase power supply of 220V at 50Hz, with filling servo power of 1kw, conveying servo power of 0.75kw, and an optional feeding pump power of 0.55kw.

Is maintenance easy for this filling machine?

Yes, the machine is designed for easy maintenance. Routine tasks like rotor and sealing ring replacement can be performed by simply removing the pump cover without needing to disassemble the entire pump body.

What sealing mechanism does the machine use?

The machine utilizes mechanical friction seals, which are designed to be easy to remove and replace, enhancing the convenience of maintenance.

Can the machine handle liquids of varying viscosities?

Yes, the rotary pump mechanism is capable of handling a variety of viscosities, making it suitable for different types of liquids.

What features enhance the convenience of using this filling machine?

The machine features a 'Fuma Wheel' for easy mobility, a stop-and-go conveyor belt for guaranteed liquid filling speed, and customizable structures for improved leveling.

What happens if the rotor is misaligned?

If the rotor is eccentrically stuck due to misalignment or wear, it can lead to scrapping of the entire rotor pump. It's essential to maintain proper alignment to avoid such issues.

Is training provided for operating this machine?

Typically, manufacturers provide operational training and manuals to ensure users can efficiently and safely operate the filling machine.

What industries can benefit from using this filling machine?

This machine is widely used in industries such as food, pharmaceuticals, and chemicals, where precise liquid filling is essential.

How does the machine improve processing errors?

The entire leveling structure of the machine is customized and improved to compensate for processing errors, ensuring uniform clearance between the rotor and the cavity.
