Exclusive Wood Finger Joint Machine With Automatic Finger Joint Line

MXZ3515 Auto Finger Joint Shaper & Related Equipment

These advanced woodworking machines are designed for high-efficiency finger joint processing, making them ideal for use in wood-based product manufacturing such as furniture, doors, and timber. The machines feature precision control, automatic glue application, and robust construction for reliable, long-term operation in industrial environments.

Product Descriptions:

1. MXZ3515 Auto Finger Joint Shaper

• Max Working Width: 600mm
• Max Working Thickness: 150mm
• Max Working Length: 1200mm
• Cutter Tenon Spindle Diameter: φ70mm
• Tenon Cutter Diameter: φ160mm
• Cutter Tenon Spindle Rotation Speed: 6000rpm
• Main Saw Blade Rotation Speed: 5600rpm
• Working Air Pressure: 0.5-0.8Mpa
• Cutter Motor Power: 11KW
• Saw Motor Power: 5.5KW

2. MXZ3515T Auto Finger Joint Shaper (with Glue Application)

• Max Working Width: 600mm
• Max Working Thickness: 150mm
• Max Working Length: 1200mm
• Cutter Tenon Spindle Diameter: φ70mm
• Tenon Cutter Diameter: φ160mm
• Cutter Tenon Spindle Rotation Speed: 6000rpm
• Main Saw Blade Rotation Speed: 5600rpm
• Working Air Pressure: 0.5-0.8Mpa
• Cutter Motor Power: 11KW
• Saw Motor Power: 5.5KW

3. MHZ1560A Auto Finger Joint Assembler

• Max Process Length: 6200mm
• Process Width: 30-150mm
• Process Thickness: 18-80mm
• Saw Motor Power: 3KW
• Main Saw Blade Size: φ355mm
• Oil Pump Motor Power: 4KW
• Main Saw Blade Rotation Speed: 3700rpm
• Working Air Pressure: 0.5-0.8Mpa
• Max Jointing Force: 5.5KW

4. MF761A Chain Conveyor

• Max Join Wood Width: 150mm
• Max Join Wood Thickness: 80mm
• Min Join Wood Width: 30mm
• Min Join Wood Thickness: 15mm
• Total Power: 3KW
• Overall Dimensions (L x W x H): 3590mm x 750mm x 1210mm

5. MF746A Roller Conveyor

• Max Join Wood Width: 150mm
• Max Join Wood Thickness: 80mm
• Min Join Wood Width: 30mm
• Min Join Wood Thickness: 15mm
• Max Convey Wood Length: 700mm
• Total Power: 2.25KW
• Overall Dimensions (L x W x H): 2020mm x 1660mm x 1055mm

6. MF762 Upender

• Max Join Wood Width: 150mm
• Max Join Wood Thickness: 80mm
• Min Join Wood Width: 30mm
• Min Join Wood Thickness: 15mm
• Max Convey Wood Length: 700mm
• Total Power: 0.75KW
• Overall Dimensions (L x W x H): 3200mm x 1670mm x 1070mm

Key Features:

• Automatic Operation: Streamlined processes, ensuring high-efficiency and reduced labor costs.
• Glue Application (MXZ3515T): Automatic glue application ensures consistent joint formation, especially important for stronger, more reliable finger joints.
• Precision & Speed: High rotation speeds and precision settings allow for fast and accurate processing.
• Air Pressure Range: Operates efficiently within a range of 0.5-0.8Mpa, ensuring smooth, continuous operation.
• Durability: Built to withstand high-volume operations, ensuring longevity and minimal downtime.

Applications:

• Furniture Manufacturing: Ideal for producing finger-jointed timber for use in furniture and cabinetry.
• Door and Window Production: Widely used in industries requiring precise and strong wooden joints.
• Wood Processing: Suitable for any woodworking operation that requires high-quality jointing and efficient production.

These machines offer an excellent balance of automation, precision, and performance, enabling manufacturers to meet high demand with top-quality products.
