Product Description
Product Description
Product profile
This product is composed of high quality lithium iron phosphate core (series-parallel connection) and advanced BMS management system. It can be used as independent DC power supply or as "basic unit" to form a variety of energy storage lithium battery power supply systems. It has high reliability and long life. Products developed for applications such as power grid energy storage, industrial and commercial energy storage, home high voltage energy storage, high voltage UPS, and data room.
| Model | GBP 220100 | GBP 220200 | GBP 384100 | GBP 384200 | GBP 384300 | GBP 384500 | GBP 3841000 |
| Type of core | Lithium iron phosphate | ||||||
| Rated energy(KWH) | 22 | 44 | 40 | 80 | 120 | 200 | 400 |
| Nominal capacity (AH) | 100 | 200 | 100 | 200 | 300 | 500 | 1000 |
| Nominal voltage(VDC) | 220.8 | 384 | 384 | ||||
| Operating voltage range(VDC) | 179~259 | 312~450 | 312~450 | ||||
| Recommended Charge Voltage(VDC) | 242 | 420 | 420 | ||||
| Recommended discharge cutoff voltage(VDC) | 210 | 366 | 366 | ||||
| Standard charging current (A) | 50 | 100 | 50 | 100 | 150 | 250 | 500 |
| Maximum continuous charge current(A) | 100 | 200 | 100 | 200 | 300 | 500 | 1000 |
| Standard discharge current (A) | 50 | 100 | 50 | 100 | 150 | 250 | 500 |
| Maximum continuous discharge current(A) | 100 | 200 | 100 | 200 | 300 | 500 | 1000 |
| Working temperature | -20~65℃ | ||||||
| Protection level | IP20 | ||||||
| Communication interface | RS485/CAN two choose one | ||||||
| Reference Weight (Kg) | 300 | 600 | 470 | 940 | 1410 | 500 | 1000 |
| Reference size(D*W*Hmm) | 530*650*1180 | 625*550*1810 | 530*550*1810 | (625*550*2040)*2 | 530*550*2020*3 | 530*550*2020*5 | (625*550*1600)*10 |
Detailed Images
Please follow the following steps to implement battery connection:
Remove orange and black connectors from battery module
Insert the connector into the connectors
Tighten the bolt with an inner hexagonal wrench stuck M 6 the connector base
Use multimeter to measure the B+ and B- on the high-volt battery box to see if the total pressure is normal
Test the temperature on the connector with a temperature measuring gun after electrification for a period of time to prevent the bolt from not tightening and cause the temperature to rise at the connection joint, resulting in the hidden danger of safety
Product Advantage
convenient installation and maintenance, easy operation
The product adopts modular design, higher integration, saving installation space; adopts high performance lithium iron phosphate cathode material, good core consistency, design service life of more than 10 years; one-key switch machine, front operation, front wiring
Over voltage protection
various functions, with single over-voltage / under-voltage, total voltage under-voltage / over-voltage, charge / discharge over-current, high temperature, low temperature, insulation and short circuit protection and recovery functions
strong compatibility
seamless docking with UPS, photovoltaic power generation and other main equipment; communication interface forms, CAN / RS 485 and so on can be customized according to customer needs, convenient system remote monitoring and flexible use.
High energy lithium electric equipment
Achieve higher energy supply, lower energy consumption, and reduceenvironmental pollution; adopt all-round, multi-level battery protection strategy and fault isolation measures to ensure the safeoperation of the system.
| Test the temperature | on the connector with a temperature measuring gun after electrification for a period of time to prevent the bolt from not tightening and cause the temperature to rise at the connection joint, resulting in the hidden danger of safety |
|---|
The EX3110-3120K Series Online UPS has a rated capacity of 20KVA.
This UPS uses high-quality lithium iron phosphate batteries.
The design service life of the battery is more than 10 years.
It is suitable for power grid energy storage, industrial and commercial energy storage, home high voltage energy storage, high voltage UPS, and data rooms.
The operating temperature range is -20 to 65 degrees Celsius.
Remove the orange and black connectors from the battery module, insert them into the connectors, and tighten the bolts with an M6 inner hexagonal wrench.
It has over-voltage, under-voltage, charge/discharge over-current, high temperature, low temperature, insulation, and short circuit protection features.
The UPS supports RS485 and CAN communication interfaces, which can be customized as per customer needs.
The dimensions vary by model, for instance, one model measures 530*650*1180 mm.
Yes, it features a modular design for convenient installation and maintenance.
Yes, it can seamlessly integrate with photovoltaic power generation and other main equipment.
Weights range from approximately 300 kg to 1000 kg depending on the model.
The UPS supports remote monitoring through its communication interfaces, allowing for flexible use.
The recommended charge voltage varies by model; for example, one model recommends 242 VDC.
The UPS is equipped with fault isolation measures to ensure safe operation, but please refer to the user manual for specific troubleshooting steps.
