Product Description

Specification

Mode Type		Blueprint-E2/18 1.8M 6ft Eco Solvent Printer
Print Head		1/2 DX5 Drop-On-Demand Micro-Piezo Print Heads
Number Of Nozzles		2880 Nozzles (2 Heads)
Color		4 Colors:Cyan, Magenta, Yellow, Black
Resolution		1440dpi (Max)/1440dpi
Height Of Print Head		2-5mm
Size Of Ink Droplet		2.5PL
Max. Print Width		1800mm
Max. Media Width		1830mm (Max)
Printing Speed	3pass	48.0sq.M Per Hour
	4pass	36.0 sq.M Per Hour
	6pass	24.0 sq.M Per Hour
	8pass	18.0 sq.M Per Hour
	12pass	12.0sq.M Per Hour
Media Feeder		Yes
Media Take-Up		Yes
Material	Max Weight	300 kgs
	Application Type	Flex,Banner,Knife Coated Substrate,Double Side Printing Banner PVC,
		Advertising Cloth,Adhesive Vinyl,One Way Vision, Mesh,
		Reflective Banner,Reflective Vinyl,Eco Solvent Media,heat transfer Paper
Ink	Type	Eco Solvent Ink,Sublimation Ink,Pigment Ink,Water Based,heat transfer ink
	Ink Tank Account	1 Liter Continuous Ink Supply
Auto Cleanning System		Auto Cleanning System With Anti Clogged Flash Spray & Moisturizing Function &A
Collision avoidance system		Optional
Picture Drying System		Fan Drying System, Infrared Heating
Media Adsorption		Multi-Section Intelligent Suction System With Adjustable Strength.
Interface		HI-USB2.0/3.0
Power	Power Voltage	AC220-240V 50-60HZ
Control Software		PrintManager
RIP Software		Ultraprint/Maintop (Photoprint Optional)
Four Heating Sections		Pre-Heater, Printing Bed Heater, Rear Heater,Printhead Heater
Operation System		MS Windows 7 & Windows 8& Windows 10
Printing Environment		Temperature: Temperature 15-35 Degrees, Humidity 30-65 Rh
Picture Type		JPG PSD TIF
Printer Dimension		W3170D860 H1350mm
Packing Dimensions		W3330D950 H1515mm
Net Weight		300 KGS
Gross Weight		400 KGS

Shipping Timeframes: All orders are processed within 2-5 business days (excluding weekends and holidays). After your order has been processed, the estimated delivery time is before 12 Dec, 2026, depending on customs, Please note that due to high demand, some items may experience longer shipping times, which will be communicated at order confirmation email.
Order Processing Time: Please allow 2-5 business days for us to process your order before it is shipped . Orders placed after 16:00 on Fridays, or during weekends and public holidays, will begin processing on the next business day. Processing times may be extended during peak seasons or sales events.
Manufacturing Time: Some products needs manufacturing time, the manufacturing process will take approximately 10-30 business days depending on the product. This timeframe may vary depending on the complexity of the product and current demand. but this will be communicated with you during order confirmation.
Returns and Exchanges: We offer a 30-day return policy for most items. If you are not completely satisfied with your purchase, you may return it within 30 days of receipt for a refund or exchange. Items must be unused, in their original packaging, and accompanied by proof of purchase. Return shipping costs are the responsibility of the customer, unless the item was damaged or defective upon arrival.

1. What is the maximum print width of the Epson 4720 plotter?

The maximum print width is 1800 mm, and the maximum media width the machine accepts is 1830 mm.

2. What print resolution and droplet size does this printer support?

Maximum resolution is 1440 dpi and the ink droplet size is 2.5 picoliters.

3. Which print heads and nozzle configuration are used?

It uses 1/2 DX5 Drop-On-Demand Micro-Piezo print heads with a total of 2880 nozzles (2 heads).

4. What colors/ink types are supported?

Standard configuration is 4-color CMYK (Cyan, Magenta, Yellow, Black). The printer supports Eco Solvent, Sublimation, Pigment, Water-based and Heat Transfer inks (as specified).

5. What are the printing speeds (productivity) for different pass modes?

Typical speeds are: 3-pass — 48.0 sq.m/hr; 4-pass — 36.0 sq.m/hr; 6-pass — 24.0 sq.m/hr; 8-pass — 18.0 sq.m/hr; 12-pass — 12.0 sq.m/hr.

6. Which media types and applications can this printer handle?

It is designed for large-format applications such as flex, banners, knife-coated substrates, double-side printed banners, PVC, advertising cloth, adhesive vinyl, one-way vision, mesh, reflective banners/vinyl, eco-solvent media and heat-transfer paper.

7. How is media handled — does it have a feeder and take-up system?

Yes. The printer includes a media feeder and a media take-up system to handle roll media and continuous printing.

8. What is the maximum media weight the machine can take?

The specified maximum media weight capacity is 300 kg.

9. What drying and heating systems are included?

The printer has a fan drying system and infrared heating. It features four heating sections: pre-heater, printing-bed heater, rear heater and printhead heater.

10. What maintenance and anti-clogging features are provided?

An auto-cleaning system with anti-clogged flash spray and a moisturizing function is built in to help prevent nozzle clogging and reduce maintenance needs.

11. Is there collision avoidance on the printer?

Collision avoidance is available as an optional feature.

12. What ink supply system does the Epson 4720 use?

It uses a 1-liter continuous ink supply system (refillable continuous ink tanks).

13. Which interfaces, control and RIP software are supported?

Interface options include HI-USB 2.0/3.0. Control software is PrintManager. RIP software options include Ultraprint or Maintop, with Photoprint available as an optional choice.

14. Which file types and operating systems are compatible?

Supported picture file types include JPG, PSD and TIF. The printer is compatible with Microsoft Windows 7, Windows 8 and Windows 10.

15. What are the physical dimensions, weight and power requirements?

Printer dimensions are W3170 x D860 x H1350 mm. Packed dimensions are W3330 x D950 x H1515 mm. Net weight is around 300 kg and gross weight about 400 kg. Power requirement is AC 220–240 V, 50–60 Hz.
