Electronics Production Machinery Smt Pick And Place Machine Desktop PCB Making Machine Smd Pick And Place For Smt Pcb Production

SKU: 1600175883364
Category: Manufacturing Machinery

R120,000

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Manufacturing Machinery
SKU:: 1600175883364

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

19 Dec, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

Pick And Place Machine Feature

1. Closed-loop control, Step servo motor with the professional flexible. 2. Pcb size: Max: 320x450mm (without tray). 320x250 (put tray).3. The smallest component can be attached 0402. The largest: 20x20mm.4. Industrial control computer: Install WIN7 system, the operation is simpler, can be networked, support remote assistance debugging.5. Independent research and development system.6. 27 kinds of plated materials.7. S deceleration, performance as same as general servo motor.8. With HD CCD Camera, accuracy and quick.9. With 2 pick and place heads, types of high-precision nozzles, compatibility as Juki.

Product Specification
System	Project	Content
Mounting system	Mounting numbers	2 pcs
	Precision	0.025mm
	Theoretical speed	6500 pcs/h
	Normal speed	5000 pcs/h
	Visual speed	3500 pcs/h
	Applicable element	RC( 0402 , 0603 , 0805 , 1206 etc)
		LED lamp beads (0603,0805,3014,5050 etc)
		Chip ( SOT , SOP , QFN , BGA etc)
PCB	Minimal Size	10 x 10 mm
	maximum size	320 x 450 mm (no try)
		320 x 220 mm( with try)
	Thickness	≤ 1 mm
	Wraping allowable value	≤ 2 mm
Feeder	Quantity	27 pcs
	8 mm	20 pcs
	12mm	4 pcs
	16 mm	2 pcs
	24 mm	1 pcs
	Preposition IC	10 pcs
	Tubular material feeder	Zhengbang dedicated five tubular materials feeder one(optional)
X / Y / Z axis	X/Y axis moving range	430 x 530mm
	Z axis moving range	10 mm
Visual Camera	Quantity	2 pcs ( parts camera, PCB camera)
	Recognition capability	MAX 20 x 20mm
Control system	Syetem	Microsoft WIN7
	file format	CSV, TXT
	Air pressure	0.4 Mpa
Basic parameter	Power	150W
	Power supply	AC220V±10% 50Hz
	Main engine outline size	L 830 x W 730 x H375 mm
	Feeder outline size	L 235 x W 700 x H245 mm
	Net weight	56 kg
	Gross weight	83 kg

Product Details

Frequently Asked Questions

What is the maximum PCB size that the Pick And Place Machine can handle?

The maximum PCB size that the machine can handle is 320 x 450 mm without a tray and 320 x 250 mm with a tray.

What types of components can this machine place?

The machine can place components as small as 0402 and as large as 20 x 20 mm, including various types of resistors, capacitors, LED lamp beads, and ICs.

What is the mounting speed of the machine?

The theoretical speed of the machine is 6500 pcs/h, while the normal speed is 5000 pcs/h and the visual speed is 3500 pcs/h.

Does the machine come with a camera for visual inspection?

Yes, the machine is equipped with an HD CCD camera that provides accuracy and quick recognition capabilities.

What operating system does the control system use?

The control system is based on Microsoft Windows 7, which simplifies operation and allows for networking and remote assistance debugging.

How many feeders does the machine support?

The machine supports 27 feeders, including various sizes such as 8 mm, 12 mm, 16 mm, and 24 mm.

What is the precision of the machine?

The machine has a precision of 0.025 mm, ensuring high accuracy in component placement.

What is the weight of the machine?

The net weight of the machine is 56 kg, and the gross weight is 83 kg.
