Concrete Pumps

Electric Concrete Pumps with Boom Machine Pipe Clamp Small Mortar and Cement Concrete Pump

SKU: 1600223138619
Category: Concrete Pumps

Product Overview

R169,000

Quantity

Contact Support

Asset Finance Available

Explore funding with Afrimart's partners. Subject to provider approval.

Check Funding Options

Section:: Machinery
Category:: Concrete Pumps
SKU:: 1600223138619

Sold by Afrimart Online

Afrimart Online

Welcome to Afrimart Online, the premier destination offering an extensive range of products and streamlined services tailored to optimize your cross-border import procurement process. Our comprehensive platform serves as...

B21, China Town Mall, Midrand

011 805 0386

View Store

Delivery & Shipping

Estimated delivery

22 Dec, 2026

Delivery timing is confirmed with your order.

Learn more about our Shipping Policy

Shop with Confidence

Shipping
Information Returns
Policy Product
Support

Product Description

Product Overview

Concrete pump

Our company’s high-performance concrete pumps have been widely used in each country. The products are exported to many countries in water conservancy, electric power, railways, highways, tunnels, mining, national defense, and other industries, and enjoy a high reputation.

FEATURES AT A GLANCE

Model	CPE-15	CPE-22	CPE-30
Input voltage	380VAC three phase	380VAC three phase	380VAC three phase
Rated power	15KW	22kw	30kw
Oil pump	50type	63type	80/100type
Max particle dia	15mm	20mm	10-30mm
Transfer capacity	6m3/h	10m3/h	12m3/h
Vertical distance	20m	40m	60m
Horizontal distance	60m	100m	150m
Outlet port dia	100mm	100mm	125mm
Tube diameter	80mm	80mm	80/100/125mm
Overall size	17007001200mm	250011001400mm	330016001550mm
Weight	600kgs	950kgs	1000kgs

1. The special pouring concrete pump for fine stone mortar with structure can realize long-distance transportation of fine stone concrete and mortar in high-rise buildings.

2. Our products have passed the BV and ISO9001 international quality system certification, and the mining concrete pump has passed the mining product safety certification.

Power

Pure copper motorPowerful, quick start and longer life.

Cooling system

The fan has strong wind, which can stably control the oil temperature below 55°, and the equipment can work continuously, which is more stable than the water tank.

Oil pump, solenoid valve

Imported oil pump, solenoid valve, well-known brand hydraulic.

Control system Operation panel

The machine is safe and reliable, easy to operate, and equipped with a remote control, which can remotely control the machine.

The machine is equipped with a remote control, remote control work, more labor-saving

Lubrication system

The machine has a hand pump, and the lubricating grease every part, making the machine more durable.

Temperature tips

Sensing the temperature of the machine at any time, it is more safe and reliable to use.

Hopper

Large capacity, more convenient to use and feed.

“S” tube valve is used to change direction, which can meet various diameters of concrete transportation.

Outlet

The large diameter of the outlet and the high pressure can meet the transportation requirements of high-rise buildings and long-distance construction

Intelligent mobile joystick

Easy operation and flexible steering.

Soild tire

solid tireRugged and easy to turn.

Concrete pump accessory display

Accessories complete, without worry after sale.

Concrete pump is suitable for floor heating backfilling, pavement pouring, indoor

construction, railway tunnels, urban subways, etc

Concrete pump construction efficiency is high, easy to move, directly placed on the construction site pouring.

Frequently Asked Questions

What is the maximum transfer capacity of the Electric Concrete Pumps?

The Electric Concrete Pumps have varying transfer capacities depending on the model: CPE-15 has a capacity of 6m³/h, CPE-22 has 10m³/h, and CPE-30 has 12m³/h.

What is the maximum vertical distance the pumps can handle?

The maximum vertical distances are 20m for CPE-15, 40m for CPE-22, and 60m for CPE-30.

What is the input voltage required for these concrete pumps?

All models of the Electric Concrete Pumps require a 380VAC three-phase input voltage.

Are the pumps certified for quality and safety?

Yes, the pumps have passed BV and ISO9001 international quality system certifications and the mining concrete pump has passed mining product safety certification.

How does the cooling system work?

The cooling system features a strong wind fan that keeps the oil temperature below 55°C, allowing for continuous and stable operation.

What type of motor is used in these pumps?

The pumps are equipped with a pure copper motor, which provides powerful performance, quick starts, and a longer lifespan.

Is there a remote control feature available?

Yes, the machine is equipped with a remote control for easy and labor-saving operation.

What is the outlet port diameter for the pumps?

The outlet port diameter is 100mm for CPE-15 and CPE-22, and 125mm for CPE-30.

Can the pumps handle different types of concrete?

Yes, the pumps are designed to handle fine stone concrete and mortar, making them suitable for various construction applications.

What are the dimensions of the Electric Concrete Pumps?

The overall sizes are as follows: CPE-15 measures 1700*700*1200mm, CPE-22 measures 2500*1100*1400mm, and CPE-30 measures 3300*1600*1550mm.

What is the weight of each model?

CPE-15 weighs 600kgs, CPE-22 weighs 950kgs, and CPE-30 weighs 1000kgs.

What applications are these concrete pumps suitable for?

These concrete pumps are suitable for various applications including floor heating backfilling, pavement pouring, indoor construction, railway tunnels, and urban subways.

How is the lubrication system designed?

The lubrication system includes a hand pump that ensures all parts are lubricated with grease, enhancing the machine's durability.

What type of tires are used on the pumps?

The pumps are equipped with solid tires, which are rugged and provide easy maneuverability.

What is the purpose of the 'S' tube valve?

The 'S' tube valve is used to change the direction of the concrete flow, accommodating various diameters of concrete transportation.
