TQ series adopts the fourth generation of Dual DSP digital signal processor (SIMD core), accurate 450MHz / 40 bit floating-point mathematical operation, 24bit / 48Khz high-performance ADC / DAC. 114dB typ. Dynamic range. Pay attention to every detail of your voice and show rich voice connotation.
Product Parameter
| Display screen: | 6.1"x3.5" (156mm x 90mm), 7" high definition color TFT LCD, capacitive touch screen. |
| Channel guide screen: | 1.44" color TFT LCD screen, 13Pcs. |
| Lighting: | One-piece built-in, LED true color, 9 colors optional, adjustable brightness. |
| Audio Input: | 22-channel input: 16-channel Mic/Line, 2-channel stereo LineIN, 1-channel stereo |
| Audio output: | 18 outputs: 8 MIX bus outputs (XLR balanced interface) 4 MTRX bus outputs (1/4" TRS balanced interface) 1 stereo Main-Out L/R (XLR balanced interface) 1 stereo USB disk recording 1 channel stereo |
| Grouping: | 12 DCA Groups (with Mute), 8 Mute Groups. |
| DSP: | 4 professional effects: Chorus, Echo, Flanger, Pitch-shift, Reverb, Stereo Delay, six types of effect proce |
| USB: | USB Wi-Fi adapter included. |
| Quantization bits: | 48kHz / 24bit |
| Signal delay: | Less than 3.3 ms from any input to output |
| Faders: | 100mm electric intelligent control, accuracy=1024 steps, +10dB to -60dB/-∞ all electric faders |
| THD+N: | < 0.03% |
| Frequency response: | +/- 0.1dB |
| Dynamic range : | 103dB |
| Equivalent input noise : | -125dBu |
| Redundant output noise : | -93dBu |
| Crosstalk: | -110dB |
| Working Voltage: | 85Vac ~ 240Vac,50 ~ 60 Hz |
| Power: | 50W |
| Temperature: | Operating temperature range: 0℃~40℃ Storage temperature range: -20℃~60℃ |
| Net Weight: | 9.5 kg / 20.9 lb |
| Package Weight: | 13 kg / 28.7 lb |
| Net dimension (W x D x H): | 465 x 553 x 206 mm / (18.3 x 21.8 x 8.1 in) |
| Package dimension (W x D x H): | 550 x 630 x 320 mm / (21.7 x 24.8 x 12.6 in) |
