3M9740B×150 Cylinder Block Surface Grinding Machine

A vertical grinding and milling machine for resurfacing engine cylinder blocks and heads, with a longer 1500 mm worktable and stepless frequency-controlled table speed.

The 3M9740B×150 restores flat, accurate surfaces on engine blocks and cylinder heads. Its 1500 mm table is 200 mm longer than the ×130 model, so it takes larger blocks, such as those from trucks, tractors, and generators, as well as longer multi-head setups. It combines grinding and milling in one vertical machine, and a gear motor and ball screw drive the table smoothly. Special fixtures allow multi-angle grinding of cylinders and heads, and resin sand castings keep deformation low so the machine holds its accuracy over time.

Key Features

• Longer 1500 mm work capacity: Handles workpieces up to 1500 mm long, 350 mm wide, and 800 mm high.
• Grinding and milling in one: A vertical machine with high grinding efficiency and accuracy.
• Smooth, stable table drive: Gear motor and ball screw, with stepless frequency control for convenient, steady speed adjustment.
• Variable spindle speed: Frequency-controlled main motor runs at 1400 or 700 r/min, so you can match the speed to the material and the job.
• Multi-angle grinding: Special fixtures let you grind cylinder blocks and heads at different angles.
• Dimensionally stable construction: Resin sand castings keep deformation small, with a neat, clean finish.
• Coolant system included: A cooling box with piping keeps the workpiece and wheel cool for a better surface finish.
• Complete starter accessories: Includes the grinding disc, dresser, diamond pen, balancing stand, and the main tools needed to start work.

Technical Specifications

Standard Accessories

• Parallel support C
• Grinding disc
• Grinding wheel dresser
• Cooling box and pipe
• Diamond pen
• Wheel balancing stand
• Mill cutter
• Wrench
• Bushing spanner
• Balance arbor

Optional: Universal support, for holding a wider range of cylinder blocks and heads.

Applications

Engine rebuilding and reconditioning shops, automotive and truck repair workshops, machine shops, and engine remanufacturing plants, for resurfacing cylinder blocks and heads on cars, trucks, tractors, and generators.
