CNC Electric Concrete Drill Machine Magnetic Drilling Machine Retail

The DX-60 is suitable for drilling hard concrete and steel and is described as ideal for construction, renovation, metalworking, fabrication, maintenance and repair tasks. Use appropriate bits for each material.

Maximum drilling diameter is 50 mm.

The motor is 1.5 kW and the machine is rated for 220–240 V.

Spindle speed range is 250–600 r.p.m., with common drilling speeds noted as 250 and 450 r.p.m. for different materials.

Magnetic adhesion is rated at 15,000 N, providing strong holding force for stable operation on suitable flat ferrous surfaces.

Stroke is 170 mm and maximum cutting depth is 75 mm.

The machine uses an MT3 (Morse Taper 3) shank. Use compatible arbors and tooling for MT3.

The unit weighs 19 kg and its dimensions are 375 × 230 × 450 mm, making it relatively lightweight and portable for a magnetic drilling machine.

Yes — the DX-60 is described as having drilling and tapping capabilities. Tapping typically requires the correct tap adapter and tooling; verify procedure and tooling compatibility before tapping.

The model name includes 'CNC,' but the provided description does not detail built-in CNC controls. For CNC functionality, controller options or retrofits may be available — check with the manufacturer or seller for specific CNC controllers, interfaces, and software compatibility.

Always wear PPE (safety glasses, gloves, hearing protection), ensure the magnet is on a clean, flat ferrous surface with full adhesion before starting, secure workpieces as needed, keep hands clear of the cutter, and follow lockout procedures before servicing. Do not exceed the magnet's rated thickness/conditions.

Regularly clean the magnetic base and spindle area, inspect and replace worn carbon brushes if applicable, lubricate moving parts per the manual, check fasteners, and service the motor and gearbox according to the manufacturer's schedule.

Recommended accessories include compatible annular cutters, pilot pins, MT3 arbors/adapters, tap adapters for tapping, a coolant or cutting-fluid system for metalwork, and appropriate wrenches. Verify what is included with your purchase.

For metal drilling use cutting fluid or a coolant system to extend cutter life and improve results. For concrete-specific bits, follow the bit manufacturer's guidance (some concrete drilling uses water cooling; others require dry/hard material bits).

Warranty and support details are not specified in the description. Contact the seller or CHTOOLS directly for information on warranty terms, spare parts availability, and authorized service centers.
